Symbols T1, T2 and T3 on the display indicate the three tariffs available on the device.
The corresponding symbol flashes to indicate the selected tariff.
Instruction Manual
Table 13 (Continuation): Screens of the e
Inductive Reactive Energy Tariff 1, T1 (M/Kvar
Inductive Reactive Energy Tariff 2, T2 (M/Kvar
Inductive Reactive Energy Tariff 3, T3 (M/Kvar
Total Inductive Reactive Energy (M/Kvar
Consumption and generation values
Only available for the 4 quadrant option.
Capacitive Reactive Energy Tariff 1, T1 (M/Kvar
Capacitive Reactive Energy Tariff 2, T2 (M/Kvar
Capacitive Reactive Energy Tariff 3, T3 (M/Kvar
Total Capacitive Reactive Energy (M/Kvar
Consumption and generation values
Only available for the 4 quadrant option.
Consumption and generation values
CO
CO
CO
Consumption and generation values
No. of hours Tariff 1, T1(hours)
No. of hours Tariff 2, T2(hours)
No. of hours Tariff 3, T3(hours)
profile�
3
Parameters (units)
Cost Tariff 1, T1 (cost)
Cost Tariff 2, T2 (cost)
Cost Tariff 3, T3 (cost)
Total Cost (cost)
Emissions Tariff 1, T1 (kgCO
2
Emissions Tariff 2, T2 (kgCO
2
Emissions Tariff 3, T3 (kgCO
2
Total CO Emissions (kgCO
2
Total No. of hours (hours)
