3�4�3�- LIST OF TERMINALS, CVM-C10-FLEX MODEL
14
Table 6: List of terminals of the CVM-C10-FLEX�
1 : A1 Auxiliary power supply.
2: A2 Auxiliary power supply.
3: A(+), RS485
4: B(-), RS485
5: GND, for RS485 and digital inputs.
6: I1, digital input 1 / selection rate.
7: I2, digital input 2 / selection rate.
8: V
Voltage input L1
L1,
9: V Voltage input L2
L2,
2
1
POWER SUPPLY
Ph-Ph
520V ~
V
L1
8 9
Figure 3:Terminals of the CVM-C10-FLEX�
Device terminals
10: V , Voltage input L3
L3
11: N, Neutral
12: L1
Current input L1
,
13: L2, Current input L2
14: L3, Current input L3
15: LN, Current input LN
16: C, Common for current inputs
17: SHLD, GND for current inputs
3
RS485 INPUTS
A(+) B(-) I1 I2
GND
Ph-N
300V ~
FLEX-MAG (100mV~ )
V V N
L1 L2 L3 LN C SHLD
L2 L3
10 11 12 13 14
5
4 6
7
15 16 17
