Dimensions ( Figure 35)
Weight
Surround
Attachment
Safety of electronic measuring units
Electromagnetic compatibility (CEM)� Part 6-3: Generic standards� Emission
standard for residential, commercial and light industry environments�
Electromagnetic compatibility (CEM)� Part 6-1: Generic standards� Immunity in
residential, commercial and light industry environments
Coordination of the insulation of units installed in low voltage systems (net-
works)�
Test for flammability of plastic materials for parts in devices and appliances
90
Environmental features (CVM-C10-ITF and CVM-C10-ITF-IN)
(20)
Environmental features (CVM-C10-MC, CVM-C10-MC-IN, CVM-C10-mV and CVM-C10-FLEX)
(20)
Digital inputs
(19)
NPN Potential free contact
Communications
Modbus RTU
RS-485
Modbus RTU
9600 - 19200
1 - 2
without - even - odd
User interface
LCD Custom COG
Capacitive, 3 keys
-10ºC ... +60ºC
-10ºC ... +65ºC
Front panel: IP51 (IP64 with accessory)
-5ºC ... +45ºC
-10ºC ... +50ºC
Front panel: IP51 (IP64 with accessory)
Mechanical features
96.7x96.7x62.5 mm
Self-extinguishing V0 plastic
Standards
2
optoisolated
BACnet
MS/TP
BACnet
1
without
3 LED
5 ... 95%
2000 m
IP21
5 ... 95%
2000 m
IP21
330 gr
Panel
UNE EN 61010: 2010
UNE EN 61000-6-3:2007
UNE EN 61000-6-1:2007
IEC 664:2007
VDE 0110
UL 94
