3�5�4�- MEASURING THREE-PHASE NETWORKS WITH A 4-WIRE CONNECTION CVM-C10-MC-IN
MODEL�
Note: Do not connect MC current transformers to ground.
18
Measurement system:
V V V
L1 L2 L3
b a
a
b
A B A B
L1
L2
L3
LOAD
N
Figure 7: Three-Phase measuring with a 4-wire connection, CVM-C10-MC-IN model�
The MC transformer secondary value is set to 0.250 A (fixed value)
