4�5�2� e PROFILE
3
This profile is identified with the e
The installation's consumed and generated energy are displayed on the e
The installation status is also displayed:
A long keystroke (3 sec) of key
The generation values are identified with the negative sign on the screen, which appears in front of
each parameter.
A long keystroke (3 sec) of key
Use keys
42
symbol on the bottom of the screen (
3
Figure 31: CVM-C10 screen with the e
Installation is consuming energy.
Installation is generating energy.
will display the generation values.
will display the consumption values.
and to browse the different screens (short keystroke).
Screen
Table 13: Screens of the e profile�
3
Parameters (units)
Active Energy Tariff 1 , T1 (M/KWh)
Active Energy Tariff 2 , T2 (M/KWh)
Active Energy Tariff 3 , T3 (M/KWh)
Total Active Energy (M/KWh)
Consumption and generation values
Only available for the 4 quadrant option.
Apparent Energy Tariff 1, T1 (M/KVAh)
Apparent Energy Tariff 2, T2 (M/KVAh)
Apparent Energy Tariff 3, T3 (M/KVAh)
Total Apparent Energy (M/KVAh)
Consumption and generation values
Only available for the 4 quadrant option.
).
Figure 31
profile�
3
profile of the device.
3
