4�10�3�8�10� CO consumption and generation emissions�
2
Table 37: Modbus memory map: CO
Configuration variable
Tariff 1 consumption emissions ratio
Tariff 2 consumption emissions ratio
Tariff 3 consumption emissions ratio
Tariff 1 generation emissions ratio
Tariff 2 generation emissions ratio
Tariff 3 generation emissions ratio
All variables must be programmed at the same time.
(7)
They have 1 decimal place.
(8)
4�10�3�8�11� Cost of energy consumption and generation�
Table 38: Modbus memory map: Cost of energy consumption and generation�
Configuration variable
Cost per kWh of tariff 1 consumption
Cost per kWh of tariff 2 consumption
Cost per kWh of tariff 3 consumption
Cost per kWh of tariff 1 generation
Cost per kWh of tariff 2 generation
Cost per kWh of tariff 3 generation
All variables must be programmed at the same time.
(9)
They have 1 decimal place.
(10)
4�10�3�8�12� Programming alarms 1 and 2 (Relays 1 and 2)
Note: Configuration parameters not available for the CVM-C10-FLEX model.
Configuration variable
Maximum value.
Minimum value
Variable code
Connection delay
Hysteresis:
latch
Disconnection delay
Contacts status
Instruction Manual
consumption and generation emissions�
2
CO emissions
2
(7)(8)
Cost per kWh
(9)(10)
Table 39: Modbus memory map: Programming alarms 1 and 2�
Programming alarms 1 and 2
Address
Relay 1 Relay 2
2AF8-2AF9 2B02-2B03
2AFA-2AFB 2B04-2B05
2AFC 2B06
2AFD 2B07
2AFE 2B08
2AFF 2B09
2B00 2B0A
2B01 2B0B
Address Valid data margin
0 - 1�9999
2724
0 - 1�9999
2725
2726 0 - 1�9999
2728 0 - 1�9999
2729 0 - 1�9999
0 - 1�9999
272A
Address Valid data margin
272C 0 - 1�9999
272D 0 - 1�9999
0 - 1�9999
272E
0 - 1�9999
2730
0 - 1�9999
2731
2732 0 - 1�9999
Valid data margin
depending on the variable
depending on the variable
Table 15
0 - 9999 seconds
0 - 99 %
0 : No
1: Yes
0 - 9999 seconds
0 : Normally open
1: Normally closed
Default
value
0
0
0
0
0
0
Default
value
0
0
0
0
0
0
Default
value
0
0
0
0
0
0
0
0
