7.33 "Record" list

［Explanation］
In the record setting, it is possible to set it variously concerning the record of the measuring data.
Refer to Section 7.19
［Setting(Main)］
Item
Record Cycle Select the record cycle.
File rec cycle Select the file rec cycle.
File overwrite Select the file overwrite function, when SD card memory full.
1 The range that can be selected by the item at the record cycle changes.
※
"100 ms" cannot be selected by the main record.
Selectable range with version less than 2.00
Record cycle Selectable file record cycle
1sec to 5sec 1hour
10sec to 1min 1hour,1day
2min to 3min 1hour,1day,1week
5min to 30min 1hour,1day,1week,1month
60min 1hour,1day,1week,1month,1year
2 Old data is deleted and operation is set when select the "ON".
※
The record operation is stopped when the amount of the memory remainder is lost when select the
"OFF".
［Setting(Sub)］
Item
Sub rec cycle Select the Sub record cycle.
Sub pre rec Select the Sub pre record.
Sub rec timing Select the Sub record timing.
DI No. Select the DI number.
1 Func key can only be set when the "FUNC key" of "Device/Other" is "OFF".
※
2 "DI No." can only be displayed when the "Sub rec timing" is "DI".
※
・About the file record cycle of sub record.
As for the sub record, the file record cycle is automatically set by the record cycle. It is not
possible to select it.
Record cycle
100mm sec
1 30sec
～
1 60min
～
［Schedule］
Item
Schedule Select the schedule.
Start time Input the value of start time.
End time Input the value of end time.
Select week Select the week. (Plurals can be selected.)
7.21 for details.
～
1
※
※2
File record cycle
10min
1hour
1day
Setting contents
Selectable range in version 2.00 or later
Record cycle
1sec to 5sec
10sec to 20sec
30sec to 5min
10min to 60min
Setting contents
1
※
Setting contents
7-48
Advanced
2
※
Selectable file record cycle
1hour,1day
1hour,1day,1week
1hour,1day,1week,1month
1hour,1day,1week,1month,1year
