7.30 "Input CH" list

［Explanation］
Various settings concerning the input channel are done. Refer to Section 7.5
［Reference］
When the operational mode is only an advanced mode, the item that "
is displayed. Refer to Section 7.1 for "Mode".
There are setting and item not displayed according to the number of input channels and set of the
other content.
An item not revocable is displayed in the gray.
［Input］
Item
Channel Select the channel number.
Input type Set the input type.
Burnout Select the Burn Out function when the input kind is "mV" and "TC"
RJC Select the RJC function.
RJC Channel Select the RJC channel.
1 RJC can only be displayed when the input type is "TC".
※
2 RJC Channel can only be displayed when the "RJC" is "Assignment channel".
※
［Scaling］
Item
Channel Select the channel number.
Scaling Set the scaling and square rooter.
Range Input the value of range.
Ind. Value Input the Ind. value.
Ind. value DP Set the Ind. value DP.
Set the unit.
Unit
It is possible to select it from unit prepared beforehand or the unit that
sets the user.
1 Scaling can only be displayed when the input type is "DC voltage" or "DC current".
※
2 These items can only be displayed when the "Scaling" is "ON" or "Square root ON".
※
［Display］
Item
Channel Select the channel number.
Input the TAG.
TAG Tag can display it instead of the channel. Display the channel
operation screen for item 6.1-
Description Set the comment for input channel.
Display color Select the display color. The colors that can be selected are 16 colors.
Setting contents
1
※
2
※
Setting contents
1
※
2
※
2
※
2
※
2
※
Setting contents
⑧.
7-43
7.12 for details.
～
is attached to "Advanced"
○"
Advanced
Advanced
Advanced
○
○
