[SNTP1]
Items
Current time and
Displays the current time and date.
date
Select ON/OFF of the SNTP client function. If ON is set, time data is received from
SNTP server and time calibration is carried out.
SNTP client
When the correction of the time is attempted using the SNTP function during the
function
recording process, correction is not performed if there is a difference of ±5 minutes or
more from the current time. If the difference is 5 minutes or less, perform correction
by reducing the difference little by little so that the time approaches the current time.
SNTP server
Input the SNTP server address.
address
Time calibration
Input the time calibration interval value.
interval
Execution of
Execute time calibration immediately. However, time calibration cannot be executed
calibration
during the recording process.
[SNTP2]
Items
Select ON/OFF of the function for acquiring the time when turning on the power
Time acquisition
supply, Enabled only when the SNTP function is turned ON. If the power supply is
when the power
turned on when On is set, the recording process will not be started until the time data
supply is turned on
is acquired.
Time zone (UTC) Select the time zone.
SNTP server
Select ON/OFF of the SNTP server function.
function
[FTP]
Items
User name
Input the user name.
Password
Set the password. (No space can be used for the password.)
Level
Select "Administrator" or "User" as the access level.
[Modbus1]
Items
Station number
Input the station number.
Parity
Select "None", "Even" or "Odd" for the parity function.
Stop bit
Select "1bit" or "2bit" as the stop bit.
Communication
Select "9600bps", "19200bps" or "38400bps" as the communication speed.
speed
Modbus TCP
Input the duration until the reception timeout occurs.
Reception timeout
[Modbus2]
Items
Communication
Select "Modbus TCP(Ethernet)" or "Modbus TCP + RTU" as the Modbus operation.
type
Select "Slave" "Master (Rem. AI)" or "Master (General)" as the Modbus RTU
Master/slave
operation.
Sending timeout
Set the timeout for when the master is working.
Auto retry
Set the auto retry time for when the slave is disconnected.
Acquisition
Set the interval for acquisition from slave devices in case of the Master (General).
interval
Settings
Settings
Settings
Settings
Settings
8-35
Advanced
Advanced
Advanced
Advanced
Advanced
