8.19 Setting the file format

［Explanation］
The file format of record data is set.
Note: When the recorder is in recording, the setting cannot be changed.
［Operation］
Select the Device/Other key ⇒ File format key on the System.
File format
①
The file format of record data is selected.
Binary ：Recorded data is preserved on the SD card by the binary form.
Binary+CSV：Recorded data is preserved on the SD card by the binary form and CSV form.
(A binary file can refer by the historical trend and data viewer of recorder. Moreover, the CSV
file can do only writing, it cannot be read by a recorder. A CSV file can be referred to by Excel
etc.)
When you convert the folder into the CSV file, the following 2 files are made.
● ***dmt.csv file：Trend file
● ***dme.csv file：Event file
The record date is written in the part of "***".
※
Ex）Record start at 02/19/2011 12:34:56
Record date is "110219123456".
8-24
①File format
