7.18 Setting the automatic change function of a display group

［Explanation］
In a realtime trend screen, a group is automatically switched at a fixed interval.
(It supports since recorder version 1.30.)
［Operation］
Select the Display key
Auto display
①
ON/OFF of an auto display function is chosen.
Only the group from which the item of the Display key of a Group name key is set to "ON"
switches a display. (Refer to Section 7.15 for Display key.)
Change cycle
②
The cycle which switches a group is chosen from "5 sec", "10 sec", "15 sec", "30 sec", and "60
sec".
Auto display key on the Parameter.
⇒
7-27
①Auto display
②Change cycle
