No. Log
37 Set: Record-Setting(Main)
38 Set: Record-Setting(Sub)
39 Set: Record-Schedule
40 Add: Others-Unit
41 Edit: Others-Unit
42 Delete: Others-Unit
43 Set: Others-Message
44 Set: Others-DI
45 Set: Others-ProductsDisplay
46 Set: Others-Int.SP DO
47 Set: Others-Progress time
Execute: Others-Progress
48
Time-Manual reset
49 Execute: Others-Param initial
50 Execute: SD/Param-SD remove
51 Execute: SD/Param-SD format
52 Execute: SD/Param-Param save
53 Execute: SD/Param-Param load
54 Execute: Log output
55 Set: Comm.-Ethernet1
56 Set: Comm.-Ethernet2
57 Set: Comm.-SNTP1
58 Execute: Comm.-SNTP1 Cal Start
59 Set: Comm.-SNTP2
60 Add: Comm.-FTP user
61 Edit: Comm.-FTP user
62 Delete: Comm.-FTP user
63 Set: Comm.-Remote AI
64 Set: Comm.-ModbusMas.
65 Set: Comm.-Modbus1
66 Set: Comm.-Modbus2
67 Set: Device/Other-LCD
68 Set: Device/Other-Clock
69 Set: Device/Other-FUNK key
70 Set: Device/Other-File format
71 Add: Device/Other-Jump menu
72 Delete: Device/Other-Jump menu
73 Set: Device/Other-Mode
When logs are generated
When the OK key on the " Setting(Main) " setting screen in the Record
is touched
When the OK key on the " Setting(Sub)" setting screen in the Record is
touched
When the OK key on the " Schedule " setting screen in the Record is
touched
When a new unit is added in the "Unit" setting in Others
When an existing unit is edited in the " Unit" setting in Others
When an existing unit is deleted in the " Unit " setting in Others
When the OK key on the " Message " setting screen in the Others is
touched
When the OK key on the " DI " setting screen in the Others is touched
When the OK key on the " ProductsDisplay " setting screen in the
Others is touched
When the OK key on the " Int.SP DO " setting screen in the Others is
touched
When the OK key on the " Progress time " setting screen in the Others
is touched
When " Manual reset " in the Progress Time is executed
When " Param initial " in the Others is executed
When " SD remove " in the SD/Param is executed
When " SD format " in the SD/Param is executed
When " Param save " in the SD/Param is executed
When " Param load " in the SD/Param is executed
When " Log output " is executed
When the OK key on the " Ethernet1 " setting screen in the Comm. is
touched
When the OK key on the " Ethernet2 " setting screen in the Comm. is
touched
When the OK key on the " SNTP1 " setting screen in the Comm. is
touched
When " Cal Start " in the SNTP1is executed
When the OK key on the " SNTP2 " setting screen in the Comm. is
touched
When a new FTP user is added in the "FTP" setting in Comm.
When an existing FTP user is edited in the "FTP" setting in Comm.
When an existing FTP user is deleted in the "FTP" setting in Comm.
When the OK key on the " Remote AI " setting screen in the Comm. is
touched
When the OK key on the " ModbusMas. " setting screen in the Comm. is
touched
When the OK key on the " Modbus1" setting screen in the Comm.i s
touched
When the OK key on the " Modbus2" setting screen in the Comm. is
touched
When the OK key on the " LCD " setting screen in the Device/Other is
touched
When the OK key on the " Clock " setting screen in the Device/Other is
touched
When the OK key on the " FUNK key " setting screen in the
Device/Other is touched
When the OK key on the " File format " setting screen in the
Device/Other is touched
When a new jump menu is added in the "Jump menu" setting in
Device/Others
When an existing jump menu is deleted in the "Jump menu" setting in
Device/Others
When the OK key on the " Mode " setting screen in the Device/Other is
touched
