6． Display Function; Basic Composition Of Data Display Screen - Toho Electronics TRM20A Operation Manual

6.1 Basic composition of data display screen

①Group screen name
⑥Scale display
⑦Data display area
⑧Measured value display area
⑨Event display area
Group screen name
①
Display the screen name ("Display Name") that was set arbitrarily. The group screen can be
changed by touching.
Clock display
②
Upper stage：Displays currently date and time.
Lower stage：Displays date and time in cursor area, when Historical trend display.
When the progress time display is set "ON", and displayed a Realtime trend, progress time is
displayed.
(Refer to Section 7.25 for progress time. (It supports since recorder version 1.30.))
Change trend
③
The type of trend display can be changed by touching.
The name corresponding to the trend screen displayed now is displayed.
REAL：Real time trend display
HIST：Historical trend display
Graph type
④
The type of graph display can be changed by touching.
("Horizontal trend display"
display" "Event log"
⇒
Change display
⑤
The displaying method of screen can be changed by touching.
("Display all ON"
display area OFF"
ON" ...)
Scale display
⑥
Display scale on the "
the channel is changed, when each channel point of "
6． DISPLAY FUNCTION
③Change trend
⑮Internal memory
"Vertical trend display"
⇒
"Horizontal trend display"...)
⇒
" Scale display OFF"
⇒ ⑥
" Scale plate OFF", "
⇒ ⑥
Data display area". The scale width and display color corresponding to
⑦
④Graph type
⑪SD card loading /
writing status display
"Bar graph display"
⇒
" Scale display ON", "
⇒ ⑥
Measured value display area OFF"
⑧
Measured value display area" is touched.
⑧
6-1
②Clock display
⑤Change display
⑩Event flag display area
⑭Sub record display
⑬Main record display
⑫Memory remainder
capacity display
⇒
Measured value
⑧
"Display all
⇒
"Digital
