7.14 Setting the timer of channel

［Explanation］
To execute reset of the input value at the set interval time, "T1 timer (sec)", "T2 timer (min)" of
each channel is set.
Note: When the recorder is in recording, the setting cannot be changed.
［Operation］
Select the Calc. CH key
T1 timer (sec)
①
The T1 timer (sec) is set. (1 to 9999)
Please input an arbitrary T1 timer (sec) from the numeric input screen, and set it with the OK
key.
T2 timer (min)
②
The T2 timer (min) is set. (1 to 9999)
Please input an arbitrary T2 timer (min) from the numeric input screen, and set it with the OK
key.
The content of the timer can be selected according to the following 6 kinds besides the
above-mentioned.
(A set value is fixation, and not changes. Moreover, a set value is set from the parameter loader.
Refer to Section 2.3 of "PARAMETER LOADER INSTRUCTION MANUAL" for details)
Item
T3 Reset is executed at twelve o'clock (midnight) every day.
T4 Reset is executed at twelve o'clock (midnight) of Sunday every week.
T5 Reset is executed at twelve o'clock (midnight) of the first every month.
T6 Reset is executed at every o'clock. (※1)
U1 Reset by DI. (※2)
U2 Reset by DI. (※1) (※2)
(It supports since recorder version 1.30.)
※1
To set it, "U1" or "U2" is selected by Others key ⇒ DI key.
※2
(Refer to Section 7.24 for DI key.)
Timer key on the Parameter.
⇒
Content
7-23
①T1 timer (sec)
②T2 timer (min)
