7.5 Setting the input spec

[Explanation]
For select of the input types for each channel (thermocouple, resistance bulb and DC voltage input),
and the presence of Burn Out function can be set.
Note: When the recorder is in recording, the setting cannot be changed.
[Operation]
Select the Input CH key
The content of the display is different according to the input kind of setting.
⑥No selected range
Channel No.
The set channel is selected. (The selection range becomes CH13
Input type
The input type select display can be displayed by selects "
The list of input type can be displayed by touching input group. Selects the input signal touching,
and sets OK key touching. (The selected item is displayed in aqua.)
The display can be changed by touching arrow key (
Touch the Chancel key when not changing.
Input group
Input key on the Parameter.
CH48 in the "Calc. CH.".)
Input type" touching.
) or sliding scroll bar.
▲, ▼
7-7
①Channel No.
②Input type
③Burn Out
④RJC
⑤RJC channel
⑥OK, Cancel key
