7.34 "Others" list

[Explanation]
Various settings concerning the others are done. Refer to Section 7.22
[Unit]
Item
Unit
The edit display of new unit can be moved by touching "Add".
[Message]
Item
Message No.
Select the Message number.
Message
Input the Message.
Timing
Select the timing of message is displayed.
Channel No.
Select the channel number.
Alarm No.
Select the alarm number.
DI No.
Select the DI number.
1 This item can only be displayed when the "Timing" is "Alarm occurred" or "Alarm cleared".
2 "DI No." can only be displayed when the "Timing" is "DI ON" or "DI OFF".
[DI]
Item
DI No.
Select the DI number.
Function
Select the DI function.
Progress time
Item
Progress time ON/OFF of a progress time display is chosen.
The conditions which start or stop the count of progress time are
Condition
chosen.
Channel No.
Select the CH number.
Alarm No.
Select the alarm number.
DI No.
Select the DI number.
1 This item can only be displayed when the "Condition" is "Alarm".
2 "DI No." can only be displayed when the "Condition" is "DI".
ProductsDisplay
[
]
Item
Select to display all "production information"
Products Display
Information No .
Select to set information No.
Title
Select to set title of "production information".
Display
Select to display "production information" of Information No.
Int. SP DO
[
]
Item
Int. SP DO
Select function of "Int. SP DO".
Output relay
Select the output relay or DO.
Setting contents
Setting contents
1
1
2
Setting contents
Setting contents
1
2
Setting contents
Setting contents
7-49
7.29 for details.
Advanced
Advanced
Advanced
Advanced
Advanced
Advanced
