8.6

Output log

［Explanation］
Output log to SD card. (It supports since recorder version 2.00.)
* If you select without inserting an SD card in the recorder, an error message will be displayed.
Please insert the SD card in the recorder and select again.
［Operation］
Select the SD/Param key ⇒ Log output key on the System.
［Output destination］
A log is output to the folder called "Prm_YYMMDD_hhmmss" in the "Recorder" folder on the SD
card. The folder name is the time when the log was output.
Prm_YYMMDD_hhmmss：YY(year), MM(month), DD(day), hh(hour), mm(minute), ss(second)
For various logs, refer to Sections 6.6 and 6.7.
［Output file］
・A text file (file name: log.txt) to which eventlog, communication log, security log is input.
The contents displayed in the log display are output as a text file.
Parameter log file（File name: nnn_YYMMDD; nnn(Security log number),YY(year), MM(month),
・
DD(day)）
It is a parameter file linkedto the operation log recorded in the security log.
It is generated at the timing when the OK key of Input in Input CH is touched.
The parameter file is outputted in a form linked to the security log number as shown below. The
parameter file can be confirmed with the Parameter Loader. For the parameter log file, refer to
Section 10.19.
Security log contents in log.txt Prm_YYMMDD_hhmmss
8-6
