Configuration
Field Replaceable Unit (FRU) Configurations

Monitor-Type Selection

The J5xxx and J7xxx workstations currently support the following HP monitors:
• 19-inch (18.3-inch viewable) VGA 1600 1200 color monitor (Product Number A4575A)
• 21-inch (19.9-inch viewable) VGA 1600 1200 color monitor (Product Number A4576A)
• 18.1-inch L1800 color flat panel display VGA up to 1280 1024 (Product Number
D5065W)
• 19-inch (18-inch viewable) display VGA 1600x1200 (Product Number D8910W)
• 21-inch (19.8-inch viewable) display VGA 1800x1440 (Product Number D2847A)
• 24-inch (22.5-inch viewable) display VGA 1920x1200 (Product Number A1295A)
The monitor type does not have to be changed on these workstations since they are set up
to support these monitors. However, if for some reason the monitor type needs to be
changed, refer to Chapter 5.
NOTE Unsupported monitors may "lock up" if they cannot sync to a scan rate.
Chapter 2 43
