Field Replaceable Units (FRUs)
FRU Removal and Replacement
5. If a filler plate is installed in the I/O slot on the rear panel of the workstation, remove
the screw that secures the filler plate and remove the filler plate. Save the screw for
securing the I/O card you will install, and save the filler plate for later use.
6. Insert the I/O card in the card guides and press the card firmly and evenly into the I/O
slot connector until the I/O card is fully seated in the slot.
CAUTION To avoid damage to the connector, do not rock the I/O card from side to side
during insertion.
7. Secure the I/O card with the filler panel screw to the I/O slot.
8. Replace the PCI retainer clip.
9. Replace the workstation's top and right side panels.
10. After rebooting, use SAM to confirm that the I/O card is recognized by the system.
124 Chapter 4
