Test Call

After completing basic programming and switching on the system, make test calls.
Making an Outgoing Call:
To make an outgoing call to a remote SIP user from FXS Port, ensure that the
Destination Port Determination Method programmed for the FXS Port is 'Fixed' and
Group Type programmed is 'SIP Trunk'.
Pick up handset of the telephone instrument connected to FXS Port.
1.
You will get a dial tone.
2.
Dial 123@abc.com. The call will be routed to the dialed destination through the
3.
SIP Trunk.
Talk when the remote SIP user answers the call.
4.
Replace the handset or dial Call Disconnect Access Code to disconnect the call.
5.
Receiving an Incoming Call:
To receive an incoming call on SIP Trunk, ensure that Destination Number
Determination Method programmed for the SIP Trunk is 'Number Not Required' and
'Destination Port Determination Method' is 'Fixed'. Ensure that the Group Type
programmed for routing the call landed on the SIP Trunk is 'FXS Port'. When remote
caller calls SIP Trunk of SETU VGFX, the call is routed to the FXS Port and the
telephone instrument connected to that FXS Port starts ringing.
Pick up handset of the telephone instrument connected to the FXS Port.
1.
Talk
2.
Replace the handset after the remote caller disconnects the call.
3.
82
Matrix SETU VGFX Quick Start
