Default the SETU VGFX

SETU VGFX enables the user to default SETU VGFX and assign default values to
all programmable parameters by using 'System Default' feature. This feature will set
all parameters to factory set values except the following features:
Call Detail Records
1.
Call Progress Tones
2.
Date and Time
3.
Region Code (in Region Selection)
4.
Ring Type
5.
SIM PIN (in Mobile Port Parameters)
6.
Hardware-Slot Parameters
7.
To Default SETU VGFX, follow the steps given below:
• Click on 'Default the System' link.
• An alert message window will appear stating: "This option shall assign default
values to all the programmable parameters of the System and will Restart. Do
you want to continue?" Yes/No
• Click on 'Yes' button. All the programmable parameters shall be defaulted
except those mentioned above, followed by system restart. If you click 'No',
nothing will happen.
74 Matrix SETU VGFX Quick Start
