Destination Port Determination Method

Routing mechanism in SETU VGFX involves two things: Destination Number
Determination Method and Destination Port Determination Method. After selecting
Destination Number Determination Method for each port type, select Destination
Port Determination Method.
SETU VGFX supports following methods of determining destination port for routing
the call originated on the Source Port:
Fixed: In this method, calls originated on a Source Port are routed through a
1.
fixed port irrespective of the number dialed on the Source Port.
Destination Number Based: In this method, the call is routed to the destination
2.
port on the basis of the destination number dialed by the caller i.e. called party
number. To use this method, program 'Source Port Routing: Destination Number
Based' table. SETU VGFX will check this table and place the call on the port
programmed for the destination number dialed on the Source Port.
Calling Number Based: In this method, call is routed to the destination port on
3.
the basis of the calling party's number. To use this method, program 'Source
Port Routing: Calling Number Based' table. SETU VGFX shall check this table
while routing the call to the destination port and place the call on the port
programmed for the calling party's number in the table for that Source Port.
To program Destination Port Determination Method for FXO Ports:
Click on 'FXO Port Parameters2' link and select Destination Port Determination
Method for each FXO Port.
50 Matrix SETU VGFX Quick Start
