During initialization, System LED (STS) will display following error/events/status:
LED Status
Continuous On
1sec On - 1sec Off
500 ms on - 500ms off -
500 ms on - 500ms off -
500 ms on - 500ms off -
500 ms on - 500ms off (4 Blinks)
500 ms on - 500ms off -
500 ms on - 500ms off -
500 ms on - 1500ms off (3 Blinks)
500 ms on - 500ms off -
500 ms on - 500ms off -
500 ms on - 500ms off -
500 ms on - 500ms off (4 Blinks)
1sec On - 1sec Off
500 ms on - 500ms off -
500 ms on - 500ms off -
500 ms on - 1500ms off (3 Blinks)
During normal functioning, FXS/FXO/Mobile Port LEDs will display following error/
events/status:
LED Status
Continuous OFF
400ms On - 200ms Off -
400ms On - 3000ms Off (2 Blinks)
Continuous On
Continuous On
During Off-Hook state, FXS Port LED glows continuous Red. However, if the system is in
programming mode, the LED of the port used to enter programming mode will glow continuous
Green. After exiting programming mode, it turns Red again (displaying Off-Hook event).
You can program Port LEDs for showing the status of SIP Trunks. For example, if
you are using only two Mobile Ports then you can program the other two Mobile Port
LEDs for showing the status of SIP Trunks. (Refer
details)
10
Colour Comment
Red VoPP program download fail
Green SETU VGFX started successfully.
Network link is Up.
SIP stack is Up.
CDR buffer is not full.
Green Network link is down.
SIP stack is down.
CDR buffer is not full.
Green Network link is Up.
SIP stack is down.
CDR buffer is not full.
Red Network link is down.
SIP stack is down.
CDR buffer is full.
Red Network link is up.
SIP stack is down.
CDR buffer is full.
Red Network link is up.
SIP stack is up.
CDR buffer is full.
Colour Event/State/Status
- Port Idle/Disable
Red Incoming Ring Event
Red Off-Hook Event
Green Speech
"Checking the Status"
Matrix SETU VGFX Quick Start
for more
