LED Status
Continuous On
200ms On - 200ms Off -
200ms On - 3400 Off (2 Blinks)
Checking Status by issuing Command
By default, no LED indication is given for SIP Trunks. As a result, you cannot check
the status of SIP Trunks when no LED is programmed for showing status of SIP
Trunks. However, SETU VGFX allows you to check the status of SIP Trunks on the
LCD of the conventional phone by issuing command.
Use following command to display the status of SIP Trunk:
27-SIP Trunk-#*
Where,
SIP Trunk is from 1 to 9.
Following table shows various Error/Event/Status of SIP Trunks that can be
displayed on the LCD of the telephone instrument:
Number Field Display
(For DTMF and FSK CLI type)
Code
Only code will be displayed on the LCD of conventional phone, if CLI Type programmed on FXS
Port is DTMF and it should be interpreted using above table. Both code and description will be
displayed if CLI Type programmed on FXS Port is FSK.
Checking Status through Web JEEVES
SETU VGFX provides you the facility to check status of SIP Trunks and Network
Parameters using Web JEEVES.
Matrix SETU VGFX Quick Start
Name Field Display
(For FSK CLI type only)
Description
1 Disable
2 Registering
3 Active
4 Failed – Auth.
5 Failed - Other
Color Event/State/Status
Red SIP Registration Failed
Red SIP Authentication Failed
77
