• Allow Incoming Calls?: Enable this option to receive incoming calls on the SIP
Trunk. Incoming calls will be prohibited on the SIP Trunk, if this parameter is set
to 'No'.
Valid options: Yes/No
Default = Yes
• Maximum Calls: Program the maximum number of calls that is to be allowed on
each SIP Trunk.
Valid Range = 01 to 32
Default = 32
• Send Caller ID?: Select 'No' if you do not want to send CLI while making
outgoing calls using SIP Trunk. SETU VGFX will send SIP ID configured on the
SIP Trunk in the CLI of outgoing calls when this parameter is set to 'Yes'.
Valid options: Yes/No
Default = Yes
SETU VGFX will send Anonymous in the 'From' field if 'Send Caller ID?' option is set to 'No'.
• Send Caller-ID received on Source Port?: If this parameter is set to 'Yes',
SETU VGFX will send the CLI received on the Source port in the 'From' field of
INVITE message when an outgoing call is made using SIP Trunk else it will
check 'Send Caller ID?' option programmed for the SIP Trunk.
Valid options: Yes/No
Default = No
SETU VGFX will send Anonymous in the From field if 'Send Caller ID?' option is set to 'No',
whether 'Send Caller-ID received on Source Port' is programmed as 'Yes' or 'No'.
(Refer 'Port Parameters-SIP' feature in System Manual for details)
