user is less than the minimum length programmed for that FXS Port then
SETU VGFX will reject the call.
Valid range = 01 to 24
Default = 03
• Maximum Length: Program maximum length of destination number that
can be dialed by the user in this field. If user dials a number greater than the
number programmed for that FXS port then SETU VGFX shall strip off the
extra digits and route the call.
Valid range = 01 to 24
Default = 16
• Routing Group: Program Routing Groups (1, 2 and 3) parameters of
Destination Port Determination Method: Destination Number Based table as
shown above.
• CLI number on FXS Port: This field is applicable only when group type
'FXS' is used for routing the call. (Please refer 'Number Presentation on FXS
Port' feature in the System Manual for more details)
Improper selection of Destination Port Determination Method and Destination Number
Determination Method may result in improper and undesirable routing of the calls.
(Refer "Routing Mechanism on FXS" feature in System Manual for more details)
To program Destination Port Determination Method for Mobile Ports:
Click on 'Mobile Port Parameters2' link and select Destination Port Determination
Method for each Mobile Port.
• SETU VGFX supports following methods for determination of destination port for
the calls originated on Mobile Port.
