Port Parameters-Mobile

Click 'Mobile Port Parameters 1' link and program the following parameters.
• Port Enable?: Enable the status of the GSM Ports. You will be able to receive
incoming calls and make outgoing calls only if the GSM Port is enabled.
Valid options: Yes/No
Default = Yes
• Band Selection (MHz): The Frequency Band supported by the GSM networks
varies across countries. Therefore, select the Frequency Band used by the
GSM Service Provider(s) in the country where SETU VGFX is installed.
SETU VGFX supports following GSM frequency bands:
• 900
• 1800
• 1900
• 850+1900
• 900+1800
Default = 900+1800
If band selection is changed for any GSM Port then it will be effective only after SETU VGFX
restarts.
• SIM PIN:
the Mobile Port, enter the desired SIM PIN value here
SIM PIN value you assigned to this Mobile Port.
Valid range: 4 to 8 digits.
Default = Blank
If SETU VGFX is set to default or the software version revision is changed, the SIM PIN value does
not change.
32
If you want to use SIM PIN protection for the SIM Card inserted in
Make a note of the
.
Matrix SETU VGFX Quick Start
