Take proper precautions while installing SETU VGFX to reduce the risk of fire,
electric shock and injury to the system as well as the person using it. (Refer
Installation Precautions and Safety Instructions under "Pre-Installation Tips" topic in
the System Manual)
3.3V Battery: SETU VGFX contains 3.3V DC Manganese Lithium Battery (ML 2032-
Rechargable) of diameter 20 (-0.2)mm and height 3.2 (-0.3)mm. Battery location is marked as
'B1' on the left hand-side of J5 jumper on the Board. Battery should be replaced only by
authorized dealers of Matrix.
Mounting SETU VGFX on Wall
SETU VGFX should be installed at the airy, dust free and moisture free place.
•
Select a suitable place on the wall for mounting SETU VGFX.
•
Put the mounting template on the wall and mark the nail hole on the wall.
•
Drill a hole of appropriate size.
•
Insert the screw and tighten it leaving the screw head a few millimeters
protruded of the wall.
•
Check the strength of the nail.
•
Hang SETU VGFX on the wall.
Matrix SETU VGFX Quick Start
Installing SETU VGFX
7
