Default = '26'
• RTP Diffserve/ToS: Program RTP Diffserve/ToS for RTP traffic. If RTP QoS
is selected, SETU VGFX will send all the RTP packets with RTP QOS
setting.
Valid range = 00 to 63
Default = '46'
• SIP/ RTP Port: Program SIP/RTP Port parameters as shown below.
• SIP UDP Port: SIP UDP port defines the port on which SETU VGFX listens
for SIP messages transported over UDP.
Valid range = 1024-65535
Default = 5060
• SIP TCP Port: SIP TCP port defines the port on which SETU VGFX listens
for SIP messages transported over TCP.
Valid range = 1024-65535
Default = 5060
• RTP Listening Port: RTP Listening port defines the port on which SETU
VGFX listens for RTP packets. SETU VGFX also uses this port as source
port in RTP packets while sending RTP to remote peer.
Valid range = 1024-65525
Default = 8000
• Enable Clone MAC Address: MAC Address is the address of the electronic
hardware device coded into the device during manufacture. It is unique and
cannot be modified. MAC Address is assigned as per IANA standard. However,
it is possible to clone MAC Address, if required.
• No: If No is selected, SETU VGFX uses unique MAC Address programmed
at the factory.
• Yes: Select 'Yes' if you want to use cloned MAC Address.
Default = No
Enter desired MAC Address manually in the corresponding field.
Only Hexadecimal characters are allowed
Default = Blank
(Refer 'Port Parameters-SIP' in system manual for more details)
SETU VGFX will reboot as soon as you submit the page after changing any of the Network Port
Parameters and you will logout of the Web JEEVES.
