Matrix SETU VFX88L System Manual

Voip-fxs gateway
Hide thumbs Also See for SETU VFX88L:
Table of Contents

Advertisement

Quick Links

Download this manual
SETU VFX88L
SETU VFX44L
System Manual
Magyarországon a Matrix Telecom Ltd. képviselete,
Matrix termékek importőre, kizárólagos forgalmazója:
1095 Budapest, Mester u. 34.
Telefon: *218-5542, 215-9771, 215-7550, 216-7017, 216-7018
Fax: 218-5542 Mobil: 30 940-1970, 20 949-2688
E-mail: delton@delton.hu Web: www.delton.hu

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SETU VFX88L and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Matrix SETU VFX88L

Summary of Contents for Matrix SETU VFX88L

  • Page 1 SETU VFX88L SETU VFX44L System Manual Magyarországon a Matrix Telecom Ltd. képviselete, Matrix termékek importőre, kizárólagos forgalmazója: 1095 Budapest, Mester u. 34. Telefon: *218-5542, 215-9771, 215-7550, 216-7017, 216-7018 Fax: 218-5542 Mobil: 30 940-1970, 20 949-2688 E-mail: delton@delton.hu Web: www.delton.hu...
  • Page 2 Neither Matrix Telecom nor its affiliates shall be liable to the purchaser of this product or third parties for damages, losses, costs or expenses incurred by purchaser or third parties as a result of: accident, misuse...

  • Page 3: Table Of Contents

    Contents Section 1: Introduction ............... 5 Welcome ..................7 Packing List .................. 9 Warranty Statement ..............10 Protecting the System ..............13 Introducing the System ............... 15 Getting Started ................19 Section 2: Features and Facilities ........... 27 Access Codes ................29 Allowed-Denied Numbers ............
  • Page 4 FXS Port Parameters ..............103 Hotline ..................105 Inter Digit Wait Timer ..............107 IP Dialing .................. 108 Lifeline Port ................110 Member Selection Method ............111 Network Port Parameters ............113 Number Lists ................119 Peer-to-Peer Calling ..............120 Prefix to Domain Name Conversion ..........

  • Page 5: Section 1: Introduction

    Section 1: Introduction...

  • Page 7: Welcome

    Matrix dealers are trained and ready to give you the support you need to get the most from your Matrix product. In fact, most problems reported are minor and can be easily solved over the phone.
  • Page 8 • Routing Option-Fixed 142 • Routing Group 143 • Lifeline Port 110 • FXS Port Parameters 103 • SIP Account Parameters 149 • Peer-to-Peer Calling 120 The words ‘SETU VFX88L/VFX44L’ and ‘System’ and ‘Gateway’ are used interchangeably in the manual. SETU VFX88L/VFX44L V1...

  • Page 9: Packing List

    System Manual Matrix Packing List The ideal sales package for SETU VFX88L/VFX44L is as mentioned below: Accessories Qty. SETU VFX88L/VFX44L System Manual Adaptor 12V, 2.0Amp. Mounting Screw 30/7 Screw Grip Warranty Card set Support Card RJ11 Cable RJ45 Cable Mounting Template Technical Document CD •...

  • Page 10: Warranty Statement

    System Manual Warranty Statement Matrix warrants to its consumer purchaser any of its products to be free of defects in material, workmanship and performance for a period of 15 months from date of manufacturing or 12 months from the date of installation which ever is earlier.
  • Page 11 The Purchaser shall have to either insure the product or assume liability for loss or damage during transit. Matrix reserves the right to waive off or make any changes in its warranty policy without giving any notice. If Matrix is unable to repair or replace, as applicable, a defective...
  • Page 12 This warranty is not transferable and applies only to the original consumer purchaser of the Product. Warranty shall be void if the warranty card is not completed and registered with Matrix within 30 days of installation. SETU VFX88L/VFX44L V1...

  • Page 13: Protecting The System

    DC Adapter. Do not place this product where the cord will be misused by people walking on it. • Do not overload wall outlets and extension cords as this can result in the risk of fire or electric shock. SETU VFX88L/VFX44L V1...
  • Page 14 If the product has been dropped or the cabinet has been damaged. f) If the product exhibits a distinct change in performance. • Do not use the telephone of the product to report a gas leak in the vicinity of the leak. =X=X= SETU VFX88L/VFX44L V1...

  • Page 15: Introducing The System

    Matrix Introducing the System Introduction: • The Matrix gateway ‘SETU VFX88L/VFX44L’ is a SIP based VoIP product. Sending voice signals over Internet is called Voice Over IP (VoIP), Session Initiated Protocol (SIP) is an internationally recognized standard for implementing VoIP.
  • Page 16 Application 2: Behind the PBX • More extensions of the PBX can also access the IP Network through the gateway and make calls. 192.168.1.100 192.168.1.110 Ethernet FXO1 FXS1 Network FXS2 FXO2 Router FXS3 FXO3 FXS4 FXS5 FXS6 VFX88L SETU VFX88L/VFX44L V1...
  • Page 17 2002 192.167.1.21 192.168.1.15 VFX88L-A VFX88L-B VLAN Services Before proceeding further please ensure that you have an Internet access and at least one P2P SIP Account already set up. The default IP Address for the gateway is 192.168.001.156. SETU VFX88L/VFX44L V1...
  • Page 18 Matrix System Manual SETU VFX88L/VFX44L Photograph: =X=X= SETU VFX88L/VFX44L V1...

  • Page 19: Getting Started

    3. Basic steps for configuration. 4. Making phone calls. Getting to Know the Gateway The Matrix Gateway‘s ports are located on side panel and LEDs are on front panel. Both are explained below: • Left Side panel ports. • Right Side panel LEDs.
  • Page 20 LED (Green) is glowing. PC can be connected from Ethernet switch to access the Gateway. 4 Lifeline RJ 11 For PSTN bypass/Lifeline feature. Right Side Panel LEDs: The VFX88L has ‘10’ LEDs; These LEDs are used to signify various events. SETU VFX88L/VFX44L V1...
  • Page 21 Port Idle + SIP Green 4400 Authentication failed Incoming Ring Event 1000 4000 Continuous Off-Hook Event Continuous Speech Note: • If FXS port is disabled, user will not get LED indication. It will be same as Port Idle condition. SETU VFX88L/VFX44L V1...
  • Page 22 Red ON, Continuously Fail to download program in DSP device. {Contact Matrix} RED Blink, 1sec ON- 1sec PPPoE User Password or other data invalid. RED Blink 500ms ON-500ms Communication between VoPP and OFF-500ms ON-2sec. OFF Processor failed SETU VFX88L/VFX44L V1...
  • Page 23 System Manual Matrix Instruction for Connecting the Gateway: This section describes the instructions on, how to connect the Matrix Gateway to internet network and telephones. Unpack the box. Get satisfied with the contents and the condition of the parts. Refer to ‘Packing List’. If parts are OK, proceed with connections as shown below: •...
  • Page 24 For e.g. Registrar Server Port = 5060. • Enable SIP Account for SIP1 and also enable Outbound Proxy, if information is programmed. • If you have a second internet phone Service Account (SIP2), then SETU VFX88L/VFX44L V1...
  • Page 25 Address. For e.g. Just dial 192*168*1*21, to call the IP number 192.168.1.21. IC Call: • When an IC call for the gateway comes it will land on the extension Phone. You can also make it land on a specific Phone connected to the Gateway. SETU VFX88L/VFX44L V1...
  • Page 26 Matrix System Manual Mechanical Dimension of the SETU VFX88L/VFX44L: =X=X= SETU VFX88L/VFX44L V1...

  • Page 27: Section 2: Features And Facilities

    Section 2: Features and Facilities...

  • Page 29: Access Codes

    Matrix Access Codes What’s this? • To access some important feature the Matrix gateway supports a string of digits which can be dialed by user. This is called ‘Access Code’. • The system supports two different types of Access codes viz. Dial State and Matured State Access codes.
  • Page 30 Default = as per topic “What’s this?”. Important Point: • Conflict numbers programming is not allowed. For example, while programming the access codes, if Access code is programmed as 456 than you cannot dial any number starting with 456. SETU VFX88L/VFX44L V1...
  • Page 31 (make relay OFF) (7secs fixed) Dial tone/feature tone IDWT = Inter Digit Wait Timer ET = Error Tone Relevant Topics: 1. Supplementary Services 161 2. Emergency Number Dialing 96 3. Lifeline Port 110 4. Class of Service 86 =X=X= SETU VFX88L/VFX44L V1...

  • Page 32: Allowed-Denied Numbers

    • Denied Number List; Enter the list number programmed previously. Range = 01-24, Default = 02. For Example: • To prevent dialing of any string, enter the number string ‘4678’ in the number list-08 and enter this list number-08 in the field for SETU VFX88L/VFX44L V1...
  • Page 33 4678 and he will get ‘Error Tone’, if he has dialed this string. Relevant Topics: 1. Number Lists 119 2. FXS Port Parameters 103 3. Access Codes 29 4. Emergency Number Dialing 96 5. SIP Account Parameters 149 =X=X= SETU VFX88L/VFX44L V1...

  • Page 34: Answer Signaling On Fxs Port

    FXS port is +ve for TIP and - ve for RING in speech condition then after call maturity, TIP will become -ve and Ring will become +ve. How to program? Refer VFX88L/VFX44L Web Jeeves Pages. Click on ‘FXS Port Parameters’ SETU VFX88L/VFX44L V1...
  • Page 35 • Select signaling option from ‘None’ or ‘Battery Reversal’ for the FXS port. Program for remaining FXS ports. By default, Battery Reversal. Relevant Topics: 1. Disconnect Signaling on FXS Port 93 2. FXS Port Parameters 103 3. Call Processing 66 =X=X= SETU VFX88L/VFX44L V1...

  • Page 36: Automatic Number Translation

    “3” of the substitute number list. • After selecting the destination port for routing the call, the number SETU VFX88L/VFX44L V1...
  • Page 37 But ITSP requires only 44 for UK number dialing. Thus, 00 can be stripped off from the number string to be dialed from the gateway. • The string ‘44’ is programmed in ‘Substitute Number List whereas ‘0044’ is programmed in ‘Dialed Number List’. SETU VFX88L/VFX44L V1...
  • Page 38 Matrix System Manual Relevant Topics: 1. Number Lists 119 2. SIP Account Parameters 149 =X=X= SETU VFX88L/VFX44L V1...

  • Page 39: Backup-System Cdr

    Matrix Backup-System CDR What’s this? • In SETU VFX88L/VFX44L there is an embedded FTP server which can be used for Backup of SMDR call records. • File Transfer Protocol (FTP), a standard Internet protocol, is the simplest way to exchange files between computers on the Internet.
  • Page 40 • On successfully log In following display appears on the screen. • Select all files and right click the mouse button. Select ‘Copy to Folder’ option. • Select a path where you want to save backup files on your system. Click OK button. SETU VFX88L/VFX44L V1...
  • Page 41 • For uploading a CDR files in the system, first remove current file present in the system and then copy the new file from computer (backup source) to system. • User can also get the stored report by opening the FTP through DOS. =X=X= SETU VFX88L/VFX44L V1...

  • Page 42: Backup-System Configuration

    Matrix System Manual Backup-System Configuration What’s this? • In SETU VFX88L/VFX44L there is an embedded FTP server which can be used for Backup of System Configuration files. • For details on FTP, refer chapter “Backup-System CDR”. How to use it? •...
  • Page 43 System Manual Matrix • Select all files and right click the mouse button. Select ‘Copy to Folder’ option. • Select a path where you want to save backup files on your system. Click OK button. SETU VFX88L/VFX44L V1...
  • Page 44 (backup source) to system. • User can also get the stored report by opening the FTP through DOS. Relevant Topic: 1. Backup-System CDR =X=X= SETU VFX88L/VFX44L V1...

  • Page 45: Backup-System Software

    System Manual Matrix Backup-System Software What’s this? • In SETU VFX88L/VFX44L there is an embedded FTP server which can be used for Backup of system software files. • For details on FTP, refer chapter “Backup-System CDR”. How to use it? •...
  • Page 46 Matrix System Manual • Select all files and right click the mouse button. Select ‘Copy to Folder’ option. • Select a path where you want to save backup files on your system. Click OK button. SETU VFX88L/VFX44L V1...
  • Page 47 • For uploading a software file in the system, first remove current file present in the system and then copy the new file from computer (backup source) to system. • User can also get stored report by opening the FTP through DOS. Relevant Topic: 1. Backup-System CDR 39 =X=X= SETU VFX88L/VFX44L V1...

  • Page 48: Blind Call Transfer

    (transferee) will be released. • If remote user1 is ‘busy’ you will get Busy-tone for 5-sec. After expiry of this timer you will get error tone. • If dialed number is invalid-string, you will get ‘Error-tone’ for period SETU VFX88L/VFX44L V1...
  • Page 49 • After dialing Flash (i.e dialing the matured state access code), if there is another call for the same user, that call is not considered as Call waiting and the call will be routed to the next port as per the routing group for routing the call. SETU VFX88L/VFX44L V1...
  • Page 50 ‘ring’ and the call will get disconnected. Remote Transfer: • Matrix VFX88L supports Remote Transfer feature as explained below: • Suppose ‘A’ has dialed a number of ‘B’. ‘A’ and ‘B’ are in speech with each other.

  • Page 51: Black Listed Callers

    • If IC call is NOT, anonymous Call, the system will check this feature. If number is matched with number in the number list, the call will be rejected, provided feature is enabled. Relevant Topics: 1. Number Lists 119 2. SIP Account Parameters 149 =X=X= SETU VFX88L/VFX44L V1...

  • Page 52: Call Detail Record (Cdr)

    FXS Port Parameters for that port. • If source port of SIP Account: • Called Party Number stored in the Call records will be the Called Party Number received in the SIP Message. SETU VFX88L/VFX44L V1...
  • Page 53 • By default First and Previous will be disabled (non-editable) i.e Call records (First) from 1-20 will be displayed when you open this page. • If you click on ‘Next’, Call records from 21-40 will be displayed and SETU VFX88L/VFX44L V1...
  • Page 54 • Enter the SIP Account numbers range (from and to) which are the source ports, for all the calls for which report is desired. Range is from 1-9. Call Terminated on FXS Ports • Specify the FXS port number range (from and to), which are the SETU VFX88L/VFX44L V1...
  • Page 55 • Numbers stored are not the Numbers after applying the ANT logic. • CDR filters are applicable only for CDR report and not for storing a call record. • Call Billing information is not supported. • Scheduled Report Generation is not supported. SETU VFX88L/VFX44L V1...
  • Page 56 2003@192.168.1.156 2006 01-Mar-2007 01:53 13 FXS-2 SIP-6 2002 192.168.1.156 01-Mar-2007 01:53 14 SIP-6 FXS-7 2007 01-Mar-2007 01:53 15 FXS-1 SIP-6 2001 192.168.1.156 01-Mar-2007 01:53 16 SIP-6 FXS-8 2001@192.168.1.156 2008 01-Mar-2007 01:53 ----------------------------------------------------------------------------------------------- Matrix Setu VFX88L V1R1 =X=X= SETU VFX88L/VFX44L V1...

  • Page 57: Call Forward

    • *55-To Set Call Forward-No Reply • *56-To Cancel Call Forward-No Reply How it works? • Access code for Set/Cancel Call Forward of any type is programmable. • When call has to be routed on any FXS port, Call Forward Status SETU VFX88L/VFX44L V1...
  • Page 58 • Call Forward-Unconditional is given priority over the DND but if DND and Call Forward-Busy or Call Forward-No Reply is set, than DND will be given the priority, by the system. • Call Forward-Busy is given priority over the Call Waiting feature. SETU VFX88L/VFX44L V1...
  • Page 59 System Manual Matrix Relevant Topics: 1. Access Codes 29 2. Class of Service 86 3. Prefix to Domain Name Conversion 123 4. Supplementary Services 161 =X=X= SETU VFX88L/VFX44L V1...

  • Page 60: Call Hold

    • Can dial retrieve Hold Call Access Code. • Can dial Emergency Number. • If you dial access code or number other than above, you will get ‘Error Tone’. • If you dial Emergency Number, after holding the call, the call will be released. SETU VFX88L/VFX44L V1...
  • Page 61 • Click on “System Parameters” to program timers. Range for timers is 001-999 seconds. Default timer value for Call Hold Alert timer is 60 secs, for Call Hold Reject Timer is 180 secs. and Remote Held Reject Timer is 180 secs. SETU VFX88L/VFX44L V1...
  • Page 62 • After dialing Flash (i.e dialing the matured state access code), if there is another call for the same user, that user is not considered for Call waiting and the call will be routed to the next port from the SETU VFX88L/VFX44L V1...
  • Page 63 System Manual Matrix routing group for routing the call. • After dialing Flash if the user goes ON-Hook within Inter digit wait timer, the call will get disconnected instead of giving ring. SETU VFX88L/VFX44L V1...
  • Page 64 HOLD call present Release the Hold call. FXS goes OFFHOOK? Is FXS port ON-Hook? Ring Timer expired? Speech Error tone for 7 secs. Stop Ring on FXS port. Load Hold Alert Timer SETU VFX88L/VFX44L V1...
  • Page 65 System Manual Matrix Relevant Topics: 1. Access Codes 29 2. Class of Service 86 3. FXS Port Parameters 103 4. Call Processing 66 5. Call Progress Tones 74 6. Call Waiting 80 7. System Parameters =X=X= SETU VFX88L/VFX44L V1...

  • Page 66: Call Processing

    • Before call processing, the gateway will check ‘Class of Service’ and ‘Supplementary Features’ to allow the feature. • After you go OFF-Hook, from the Phone connected at FXS port, the system will first check whether that FXS port is enabled or disabled. SETU VFX88L/VFX44L V1...
  • Page 67 Speech is established if FXS port goes OFF-Hook. • Now if another IC call is there for the gateway and the feature Call Waiting is set then you will get Call Waiting Beeps. IC Call is not supported from the Life Line port. SETU VFX88L/VFX44L V1...
  • Page 68 Use RG for matched entry found Digits are dilaed till End of Digit Call routed to destination port as per Transfer call member selection method present? No. is dialed as per allowe/denied logic If no. is allowed it is dialed SETU VFX88L/VFX44L V1...
  • Page 69 System will send SIP ID programmed for the SIP account found (not default value '*') otherwise number programmed and local IP Address Name programmed for the FXS port, is displayed. SETU VFX88L/VFX44L V1...
  • Page 70 Is send CLI flag enable? Number is sent Number is sent without with CLI CLI (anonymous Call) Is server response ringing/OK? Caller will get busy tone or STOP Provisional Timer Ring Back Tone Speech maturity Error Tone SETU VFX88L/VFX44L V1...
  • Page 71 System will check whether number of calls (simultaneous and active) through free member found is same as maximum simultaneous outgoing calls allowed for the free member found. Max. No. of calls allowed? System send request for termination SETU VFX88L/VFX44L V1...
  • Page 72 RG as per member selection Ring on destination FXS port, if no supplementary feature is set Go OFF-Hook during Ring Timer Speech Relevant Topics: 01. SIP Account Parameters 149 02. FXS Port Parameters 103 03. Access Codes 29 SETU VFX88L/VFX44L V1...
  • Page 73 08. Call Progress Tones 74 09. Class of Service 86 10. Routing Options 133 11. Routing Group 143 12. Ring Type 130 13. Peer-to-Peer Calling 120 14. Prefix to Domain Name Conversion 123 15. Supplementary Services 161 =X=X= SETU VFX88L/VFX44L V1...

  • Page 74: Call Progress Tones

    • Each call progress tone will have following parameters associated with it: • Frequency Set (Frequency 1 and Frequency 2) to be used • Six Cadence Periods • Typical Cadence Index will look like as: SETU VFX88L/VFX44L V1...
  • Page 75 • Dialing the denied number, or • Routing is failed. • Error tone is played for the fixed time duration i.e Error tone timer=07 seconds. This timer is not programmable. But when you enter invalid command or invalid value in programming SETU VFX88L/VFX44L V1...
  • Page 76 • This tone will be played when remote party has sent a HOLD message and speech packets are not sent by the Remote end. • Remote Hold + Call Waiting Tone: • This tone will be played when user is in Remote Held state and SETU VFX88L/VFX44L V1...
  • Page 77 ON after that cadence i.e if Off time 3 is not programmed, than the tone will be played as per cadence programmed till On time 3 but than the tone will remain continuous ON. • If Off time is programmed as last cadence, than the cycle will SETU VFX88L/VFX44L V1...
  • Page 78 0.1on 0.1off 0.1on 350+440 cont. 400+450 0.1on 0.1off 350+440 0.4on 2.0off 0.225on 0.525off 0.375off 2.7off 350+440 cont. 440+480 2.0on 4.0off 480+620 0.25on 0.25off 480+620 0.5on 0.5off 0.1on 0.1off 0.3on 10.0off Relevant Topic: 1. Call Routing Tone 79 =X=X= SETU VFX88L/VFX44L V1...

  • Page 79: Call Routing Tone

    SIP Account and hears ‘ringing’. How to program? • Refer VFX88L/VFX44L Web Jeeves. • Click on ‘Call Progress Tones’. • Select Country. Default = India. Relevant Topics: 1. Call Progress Tones 74 2. Routing Options 133 =X=X= SETU VFX88L/VFX44L V1...

  • Page 80: Call Waiting

    Call Waiting beeps i.e do not want to accept the Waiting call, • User has to dial Flash-3. • Now user will remain connected to the current call and Call Waiting beeps will be stopped. SETU VFX88L/VFX44L V1...
  • Page 81 • After dialing Flash (i.e dialing the matured state access code), if there is another call for the same user, that user is not considered for Call waiting and the call is routed to the next port from the routing group for routing the call. SETU VFX88L/VFX44L V1...
  • Page 82 Matrix System Manual Relevant Topics: 1. Access Codes 29 2. Call Progress Tones 74 3. Class of Service 86 4. Supplementary Services 161 =X=X= SETU VFX88L/VFX44L V1...

  • Page 83: Calling Line Identification Presentation (Clip)

    ‘Name’ field of the LCD display. This is because, the ‘Number’ field of the phone do not support any character like ‘.’ or ‘@’. It supports only numerical value. SETU VFX88L/VFX44L V1...
  • Page 84 • Select the signaling type to be supported for FXS Port from options: None, DTMF, V.23 FSK or Bellcore FSK. Default = DTMF, for all FXS ports. Relevant Topics: 1. FXS Port Parameters 2. Routing Option-Called Number Based 135 =X=X= SETU VFX88L/VFX44L V1...

  • Page 85: Change Password

    Password will get default value. • Switch OFF the Gateway and put back the Jumper ‘J10’ in position ‘BC’. Important Point: • For the password, digits entered are displayed as “*”. Relevant Topic: 1. Default the Configuration 91 =X=X= SETU VFX88L/VFX44L V1...

  • Page 86: Class Of Service

    • If it is enabled in class of service then user will get ‘Confirmation Tone’ if the access code is dialed. How to program? Refer VFX88L/VFX44L Web Jeeves. Click on ‘Class of Service’. SETU VFX88L/VFX44L V1...
  • Page 87 Class of Service. • Thus, the status also will be changed for this feature when Class of Service is changed to disable. Relevant Topics: 1. Supplementary Services 161 2. Call Forward 57 3. Do Not Disturb (DND) 95 =X=X= SETU VFX88L/VFX44L V1...

  • Page 88: Daylight Saving Time

    • Ordinal: Program 1 , or 5 . For example if DST starts on first Sunday of January every year, then program ‘1 ’ here. Note: • For last Sunday (or other day) of the month, always set Ordinal SETU VFX88L/VFX44L V1...
  • Page 89 HH:MM (Hours-Minutes). Default = 00:00. Backward Time Adjustments: • Program all the parameters as explained for ‘Forward Time Adjustment’ except the ‘time for parameter ‘To’. Default values are same. • To: Enter the backward (delayed) time here, for the country. SETU VFX88L/VFX44L V1...
  • Page 90 23:59 (in fact 00:00 midnight) to 23:00. Hence, parameter ‘On’ will be programmed as 5th Sunday, October as per option ‘Day Month wise’ of ‘Backward Time Adjustment’. Relevant Topic: 1. Default the Configuration 91 =X=X= SETU VFX88L/VFX44L V1...

  • Page 91: Default The Configuration

    • Prefix to Domain Name Conversion Table • SIP Account Parameters-1 • SIP Account Parameters-2 • Supplementary Services • Time setting parameters except RTC Time and Date Note: • Call Detail Records will not get cleared, when the system gets default. SETU VFX88L/VFX44L V1...
  • Page 92 Matrix System Manual Important Point: • When the system is default, the system will Reset and the Reset sequence of LED will be as per chapter ‘Getting Started’. =X=X= SETU VFX88L/VFX44L V1...

  • Page 93: Disconnect Signaling On Fxs Port

    FXS port is +ve for TIP and -ve for RING in speech condition then on disconnection on other port, TIP will become -ve and Ring will become +ve. When call is disconnected, user will get Error tone. When FXS port goes ON-Hook, the Battery SETU VFX88L/VFX44L V1...
  • Page 94 Disconnect Signaling. Range = 001- 999 msec. By default, 500 msec. for all FXS Ports. Relevant Topics: 1. Answer Signaling on FXS Port 34 2. FXS Port Parameters 103 3. Call Processing 66 4. Call Progress Tones 5. Ring Type 130 =X=X= SETU VFX88L/VFX44L V1...

  • Page 95: Do Not Disturb

    • Dial *61 access code to set the feature and dial *62 access code to Cancel DND. • Refer VFX88L/VFX44L Web Jeeves. • Click on ‘Supplementary Services’ to Enable/Disable the feature. Relevant Topics: 1. Access Codes 29 2. Class of Service 86 3. Supplementary Services 161 =X=X= SETU VFX88L/VFX44L V1...

  • Page 96: Emergency Number Dialing

    • Maximum 3 digits can be entered for Emergency Number. How to program? Refer VFX88L/VFX44L Web Jeeves. • Click on Access Codes. Get the access code for dialing emergency number from ‘Lifeline Access’ field. Default = ##. SETU VFX88L/VFX44L V1...
  • Page 97 System Manual Matrix • Program maximum 4 Emergency numbers at Emergency Number 1 to 4, using maximum 3 digits (0-9, #, *). Default = Blank. Relevant Topics: 1. Lifeline Port 110 2. Access Codes 29 =X=X= SETU VFX88L/VFX44L V1...

  • Page 98: End Of Dialing

    5 digits are received. • If all options are disabled, “Inter Digit Wait Timer” is considered as End of Dialing method. • End of Dialing is programmable for each FXS port. SETU VFX88L/VFX44L V1...
  • Page 99 • End of Dialing digit will be * or # only because, other digit on the phone are 0-9 which is generally required while dialing the number. Relevant Topics: 1. FXS Port Parameters 103 2. Routing Option-Fixed 142 3. Routing Option-Dialed Number Based 139 4. Inter Digit Wait Timer 107 =X=X= SETU VFX88L/VFX44L V1...

  • Page 100: First Digit Wait Timer

    • Click on ‘FXS Port Parameters’. • Enter the time period up to which system should wait for entry of first digit after going OFF-Hook. Range = 01-99. Default = 15 sec. Relevant Topic: 1. FXS Port Parameters 103 =X=X= SETU VFX88L/VFX44L V1...

  • Page 101: Fax Over Ip (Foip)

    (Normally G.711). This time, it is responded by Gateway -1 with same vocoder G.711, and the Fax-Call is established. This is called ‘Fax Pass Through’. • Similarly the fax-call is set when user of Gateway -1 initiates the call for Fax B by dialing 456@xyz.com. SETU VFX88L/VFX44L V1...
  • Page 102 • When the call originates on the 456@xyz.com SIP Account and if destination port is programmed as Null or FAX machine is not connected to the FXS port, this call will be handled as the normal SIP call instead of FAX call. =X=X= SETU VFX88L/VFX44L V1...

  • Page 103: Fxs Port Parameters

    • This number is used only when there is a Non-Proxy SIP Account call. • It is send on the Non-proxy SIP Account call in the SIP message Default: 2001 to 2008 for FXS1 to FXS8 respectively (VFX88L). Default: 2001 to 2004 for FXS1 to FXS4 respectively (VFX44L). SETU VFX88L/VFX44L V1...
  • Page 104 • Answer Signaling-refer Answer Signaling on FXS Port • Disconnect Signal-refer Disconnect Signaling on FXS Port • Open Loop Disconnect Timer-refer Disconnect Signaling on FXS Port • Allowed-Denied Numbers • Routing Type-refer Routing Group • SIP Account Routing Group (refer Routing Group) =X=X= SETU VFX88L/VFX44L V1...

  • Page 105: Hotline

    • Status: Select to enable the feature for FXS Port, default = disable. • Number: Enter maximum 24-digit number using 0-9, *, #, ‘.’. • Timer: Enter the time period after which the system will dial out SETU VFX88L/VFX44L V1...
  • Page 106 Hot line number. Range = 0-9 sec. If ‘0’ is programmed, the number will be dialed out immediately after you go OFF-Hook. Default = 0. Relevant Topics: 1. Class of Service 86 2. Supplementary Services 161 =X=X= SETU VFX88L/VFX44L V1...

  • Page 107: Inter Digit Wait Timer

    How to program? • Refer VFX88L/VFX44L Web Jeeves. • Click on FXS Port Parameters. • Refer chapter ‘End of Dialing’. Relevant Topics: 1. FXS Port Parameters 103 2. Routing Option-Fixed 142 3. Routing Option-Dialed Number Based 139 =X=X= SETU VFX88L/VFX44L V1...

  • Page 108: Ip Dialing

    2001 only i.e. dialed number by user (if Name and Destination IP address is not found from the Peer-to-Peer Table for the dialed number) or 192.168.001.010 if only IP address is dialed by user. • Calling Station Number and Name(Number and name of the FXS SETU VFX88L/VFX44L V1...
  • Page 109 • The gateway routes the call depending on the parameters and routing types applicable for that SIP Account number. Relevant Topics: 1. Getting Started 19 2. End of Dialing 98 3. Programming Using Conventional Phone 126 4. SIP Account Parameters 149 5. Peer-to-Peer Calling 120 =X=X= SETU VFX88L/VFX44L V1...

  • Page 110: Lifeline Port

    • When user dials the number, same will be dialed out by the system. Important Point: • This port can be accessed only, from FXS1 port. Relevant Topics: 1. Access Codes 29 2. Emergency Number Dialing 96 =X=X= SETU VFX88L/VFX44L V1...

  • Page 111: Member Selection Method

    Default method is First Free for Routing Group 1 to 8 and Rotation for Routing Group 9 to 16. Member Selection Method (SIP Account RG): • Default method is First Free for 1-8 Routing Group and Rotation for Routing Group 9. SETU VFX88L/VFX44L V1...
  • Page 112 • If only 1 SIP Account is registered or non-proxy call has to be made i.e. only 1 member is programmed in the Routing Group, then member selection method ‘First Free’ should be assigned to that Routing Group. Relevant Topic: 1. Routing Group 143 =X=X= SETU VFX88L/VFX44L V1...

  • Page 113: Network Port Parameters

    • Refer VFX88L/VFX44L Web Jeeves. • Click on ‘Network Port Parameters’. Notes: • If Connection Type = DHCP, followings fields will be non- programmable: • PPPoE User ID • PPPoE User Password • IP Address • Subnet Mask SETU VFX88L/VFX44L V1...
  • Page 114 • Enter this if Connection Type = PPPoE is selected using a string of maximum 16 characters and extended ASCII Character set. Default: Blank. IP Address: • Enter this as provided by the ISP when Connection Type = Static IP is selected using string of maximum 15 characters. SETU VFX88L/VFX44L V1...
  • Page 115 • Enter the STUN Server’s listening port for SIP. • Change this field if the ITSP provides STUN Server port number other than the default. • Valid range for this field is 1024-65535. Default: STUN Server port is 3478. SETU VFX88L/VFX44L V1...
  • Page 116 • This field specifies the QoS type viz. ToS (Precedence, also called Priority) or DiffServ for voice traffic. The Gateway will send all the voice packets with this QoS setting. • If one is selected, the other one is not programmable. SETU VFX88L/VFX44L V1...
  • Page 117 • Valid range for this field is 1024-65502 (for VFX88L). • Valid range for this field is 1024-65518 (for VFX44L). Default: RTP Listen port is 8000. Important Point: • The gateway will restart after submitting this page. SETU VFX88L/VFX44L V1...
  • Page 118 Matrix System Manual Relevant Topics: 1. VoIP Basics 166 2. Glossary 182 3. Getting Started 19 4. Web Jeeves 171 =X=X= SETU VFX88L/VFX44L V1...

  • Page 119: Number Lists

    Default = Number list 01 is programmed with digits 0-9, *, # for first 12 index. All other number list are blank. Relevant Topics: 1. Allowed-Denied Numbers 32 2. Automatic Number Translation 36 3. Black Listed Callers 51 4. SIP Account Parameters 149 =X=X= SETU VFX88L/VFX44L V1...

  • Page 120: Peer-To-Peer Calling

    Note 1: As shown in table, if no match is found for the dialed number, then gateway will use first-entry for call routing. For this, the Destination Address is 192.168.001.156, Destination port is 5060, Number field is uneditable and Name field is blank. SETU VFX88L/VFX44L V1...
  • Page 121 • Destination Address: Program the Public IP Address of the peer gateway. The address of maximum 40 ASCII characters. By default, Blank. • Destination Port: Program the SIP listening port of the peer gateway. Range is 1024 to 65335 (Blank is not allowed). By SETU VFX88L/VFX44L V1...
  • Page 122 • User should get the information of Number, Destination Address and Destination Port from networking personal before configuration the P2P table. Relevant Topics: 1. Network Port Parameters 113 2. SIP Account Parameters 149 3. Call Processing 66 4. Routing Option-Dialed Number Based 139 =X=X= SETU VFX88L/VFX44L V1...

  • Page 123: Prefix To Domain Name Conversion

    IP address or user is doing Blind Transfer. • The number dialed is compared with the ‘number’ in table using ‘Best Match’ found logic. • If the match found, the digit is stripped off and domain name is added to the number. SETU VFX88L/VFX44L V1...
  • Page 124 • Prefix: Enter prefix code corresponding to Domain name of maximum 4-digits using blank, 0-9,*, #. • Domain Name: Enter name of maximum 40 characters using Blank and ASCII. Relevant Topics: 1. Blind Call Transfer 48 2. Call Forward 57 3. Call Processing 66 =X=X= SETU VFX88L/VFX44L V1...

  • Page 125: Programming The System

    • Default Static IP address of Network port is 192.168.001.156. • You can not program the MAC Address of the gateway. It is programmed at factory for each gateway. Relevant Topics: 1. Web Jeeves 171 2. Programming Using Conventional Phone 126 =X=X= SETU VFX88L/VFX44L V1...

  • Page 126: Programming Using Conventional Phone

    Each octet is of three digits. If only single digit is used then convert to three digits and then enter. For e.g. To enter IP address 192.168.9.10, enter command 11-192168009010-#*. Valid range for each octet is 000-255. SETU VFX88L/VFX44L V1...
  • Page 127 • But if you go ON-Hook after expiry of Programming Confirmation tone timer, you will not get display of IP address but will get continuous ring to indicate that it is in programming mode. Use following command to display subnet mask: 22-#* SETU VFX88L/VFX44L V1...
  • Page 128 • If FSK CLIP type is set for the FXS port, than you will get display of IP address as: 192.168.001.100, and IP, in the Name field. Relevant Topic: 1. Programming the System 125 2. Calling Identification and Presentation 83 =X=X= SETU VFX88L/VFX44L V1...

  • Page 129: Restart Gateway

    • The gateway will show an Alert message when this link is clicked: “This will Restart VFX88L/VFX44L. Do you want to continue?” • Click on ‘YES’ to restart the gateway. Wait to complete the restart process. Relevant Topic: 1. Default the Configuration 91 =X=X= SETU VFX88L/VFX44L V1...

  • Page 130: Ring Type

    OFF Time1 OFF Time2 OFF Time3 Default table for customized option: ON Time1 OFF Time1 ON Time2 OFF Time2 ON Time3 OFFTime3 msec. msec. msec. mesc. mesc. msec. 2000 How to program? • Refer VFX88L/VFX44L Web Jeeves. SETU VFX88L/VFX44L V1...
  • Page 131 • If Customized option is selected, Ring is played as per the cadence programmed. Frequency CADENCE (In Seconds) Code Country (Hz) TON1 TOFF1 TON2 TOFF2 Australia Belgium Brazil Canada China Egypt France Germany 0.79 Greece India Israel Italy SETU VFX88L/VFX44L V1...
  • Page 132 Matrix System Manual Japan Korea Malaysia New Zealand Poland Portugal Russia Singapore South Africa Spain Thailand Relevant Topic: 1. System Parameters 165 =X=X= SETU VFX88L/VFX44L V1...

  • Page 133: Routing Options

    Relevant Topics: 1. SIP Account Parameters 149 2. FXS Port Parameters 103 3. Call Processing 66 4. Routing Option-All Calls 134 5. Routing Option-Fixed 142 6. Routing Option-Dialed Number Based 139 7. Routing Option-Called Number Based 135 =X=X= SETU VFX88L/VFX44L V1...

  • Page 134: Routing Option-All Calls

    16 in which your required destination port is programmed. Important Point: • First program the Routing group and member selection method. Then enter the group number. Default = 09. Relevant Topics: 1. Routing Options 133 2. Routing Group 143 3. Call Processing 66 =X=X= SETU VFX88L/VFX44L V1...

  • Page 135: Routing Option-Called Number Based

    SIP Message is sent on FXS port and displayed. • If Received Called Party option is selected, the call is placed on the free destination port from the Routing group found and called party SETU VFX88L/VFX44L V1...
  • Page 136 How to program ‘CLI Number on FXS Port?’: • This parameter is programmed to get suitable CLI display on the phone. • Two gateways are connected through VPN or public IP address and thus Peer-to-Peer call is made between this two PBX. SETU VFX88L/VFX44L V1...

  • Page 137: Domain Name

    ‘SIP ID’ ‘Display Name’ Domain Name ‘SIP ID’ and ‘SIP ID SIP ID@IP address or ‘SIP ID’ @IP address’ or Domain Name ‘Domain Name’ IP address ‘IP Address’ IP Address When Received Called Party option is selected: SETU VFX88L/VFX44L V1...
  • Page 138 SIP ID. But for this case there is no SIP ID. Relevant Topics: 1. Routing Options 133 2. Routing Group 143 3. Call Processing 66 4. Calling Line Identification and Presentation 83 =X=X= SETU VFX88L/VFX44L V1...

  • Page 139: Routing Option-Dialed Number Based

    • First digit wait timer, Inter digit wait timer, End of Dialing digit is applicable, while dialing the number by the gateway. • Emergency Number table and Allowed and Denied number feature are also checked. Table 1 : Dialed Number String Table. SETU VFX88L/VFX44L V1...
  • Page 140 No. String of No. String of Index Dialed No. List Substitute No. List 9825065266 Automatic Number Translation list for SIP Account 2: No. String of No. String of Index Dialed No. List Substitute No. List *712123 *712456 SETU VFX88L/VFX44L V1...
  • Page 141 ‘Destination Address’ of Peer-to-Peer Table. For example, program ‘1’ for dialing on ‘SIP Account 1’. Relevant Topics: 1. Routing Options 133 2. Routing Group 143 3. Call Processing 66 4. Allowed-Denied Numbers 32 5. Peer-to-Peer Calling 120 =X=X= SETU VFX88L/VFX44L V1...

  • Page 142: Routing Option-Fixed

    Default : 9. • Program above parameters for required FXS ports from 1-8 (1-4 for VFX44L). Relevant Topics: 1. Routing Options 133 2. Routing Group 143 3. Call Processing 66 4. Allowed-Denied Numbers 32 =X=X= SETU VFX88L/VFX44L V1...

  • Page 143: Routing Group

    • When call originates on the FXS port, SIP Account Routing group is selected according to the Routing option programmed for that port and when call originates on the SIP Account, FXS Port Routing group is selected according to the Routing option programmed for that Account. SETU VFX88L/VFX44L V1...
  • Page 144 NULL First Free NULL NULL NULL NULL NULL NULL NULL First Free NULL NULL NULL NULL NULL NULL NULL Rotation NULL NULL NULL NULL NULL NULL NULL NULL Rotation NULL NULL NULL NULL NULL NULL NULL NULL SETU VFX88L/VFX44L V1...
  • Page 145 NULL NULL NULL NULL NULL NULL NULL Relevant Topics: 1. SIP Account Parameters 149 2. FXS Port Parameters 103 3. Routing Option-Dialed Number Based 139 4. Routing Option-Called Number Based 135 5. Member Selection Method 111 =X=X= SETU VFX88L/VFX44L V1...

  • Page 146: Rtc Parameters

    • The VFX88L/VFX44L gets synchronized with the specified NTP server (IP Address), which is a global server and gets the date and global time. Based on the time zone, settings, Matrix VFX88L/VFX44L shows correct time for that country. For example: •...
  • Page 147 • NTP Address: Select the required option, or select ‘Blank’ to program the time server address of your choice, with maximum 40 ASCII characters. By default, Ntp1.cs.wisc.edu. • Time Zone: Select ‘country’ where the gateway is installed. The list of countries is same as supported by ‘Windows’. SETU VFX88L/VFX44L V1...
  • Page 148 • If the option is selected other than ‘No’, user can check the ‘Time’ by refreshing this page after submitting. RTC Sync with NTP on Power ON? • Yes • No • By default, No. Relevant Topics: 1. Daylight Saving Time 88 2. Default the Configuration 91 =X=X= SETU VFX88L/VFX44L V1...

  • Page 149: Sip Account Parameters

    • Refer note 1 and 4 of the end of chapter. Name: • It is used just for information only. Enter the service provider name or person name that is using this SIP Account. • Enter the string of maximum 12-alpha numeric characters. • Default = Blank. SETU VFX88L/VFX44L V1...
  • Page 150 • Thus, this timer sets period for how long an entry remains registered with the Register Server. • This timer is used as Expire timer when message is sent for SETU VFX88L/VFX44L V1...
  • Page 151 • Enter maximum 40 characters including all ASCII characters. • Default, Authentication User ID will be blank. Authentication User Password: • It is the password associated with the user name above. • Enter maximum 16 characters including all ASCII characters. SETU VFX88L/VFX44L V1...
  • Page 152 • To reduce the packet band width occupied in the RTP for the speech, the gateway supports following types of Vocoders and it is default sequence: • G.729 • iLBC • G.723 • GSM • G.711 (μ-Law) • G.711 (A-Law) SETU VFX88L/VFX44L V1...
  • Page 153 • For Example: If DTMF option SIP INFO is selected and when IC call is received, if ‘SIP INFO’ DTMF option is requested by the remote end, then the Gateway will reply with ‘SIP INFO’ and SETU VFX88L/VFX44L V1...
  • Page 154 Default Number list=03 and range = 00-24 • Automatic Number Translation-refer chapter ‘Automatic Number Translation’. Defaults = Enable, Dialed number list = 04, Substitute number list = 05 • Routing Type-refer chapter ‘Routing Option-All Calls’ and ‘Routing Option-Called Number Based’. SETU VFX88L/VFX44L V1...
  • Page 155 • This parameter is useful to route the call to the next SIP account if number of calls to particular SIP account is maximum number of calls supported by the service provider. • It is applicable to each SIP Account for both incoming and outgoing call. SETU VFX88L/VFX44L V1...
  • Page 156 • By default this parameter field is programmed as ‘*’ for all SIP Accounts. • SE should not program the same SIP ID for different SIP account otherwise the first exact match will be considered for every call SETU VFX88L/VFX44L V1...
  • Page 157 SIP ID programmed with ‘*’ will always be considered for routing the incoming call. Relevant Topics: 1. Peer-to-Peer Calling 120 2. Getting Started 19 3. IP Dialing 108 4. Call Processing 66 5. Routing Group 143 =X=X= SETU VFX88L/VFX44L V1...

  • Page 158: Software Version/Revision Display

    • Software version revision is displayed on each Web page at right hand side bottom corner. • The display format is: VxRy (x is the version number and y is the revision number). For example, V1R2. =X=X= SETU VFX88L/VFX44L V1...

  • Page 159: Status

    • MAC Address: This displays unique MAC address for the gateway. • Gateway IP Address: This displays parameter provided by the server. • DNS Address: This display system gateway IP Address. • NAT Type: If STUN is not enabled, it is blank. If None Type is SETU VFX88L/VFX44L V1...
  • Page 160 Maximum 5 characters. • Stack Status: It displays status of ‘Stack’ like: Idle, DHCP Response Wait, PPPoE Response Wait, NAT Checking Response Wait, Construct, Error, etc. Relevant Topics: 1. Network Port Parameters 113 2. SIP Account Parameters 149 =X=X= SETU VFX88L/VFX44L V1...

  • Page 161: Supplementary Services

    • Number: Enter here the number string of maximum 24 digits (0-9, *, #, @). • Hotline Timer: Enter the time period after which the system will dial out the Hot line-number after going OFF-Hook from (1-9) seconds. SETU VFX88L/VFX44L V1...
  • Page 162 ‘Status’ and will pop-up a suitable “Error message” on Web Jeeves for rejecting the change. Relevant Topics: 1. Class of Service 86 2. Call Forward 57 3. Do Not Disturb 95 4. FXS Port Parameters 103 5. Hotline 105 6. Access Codes 29 =X=X= SETU VFX88L/VFX44L V1...

  • Page 163: System Debug

    • System Engineer can view a log of debug for different parameters on the Terminal of Remote Server. • For, the specific Card supplied by Matrix using serial port it is required to be used. For remove server, IP address of Remote Server will be programmed.
  • Page 164 • Remote Server Port: Program the port number from 1024-65535, Blank is not supported. Default = 50000. • Debug Levels: Enable the parameter for which debug-log is required. The levels are as mentioned in this chapter. By default, all are enabled. =X=X= SETU VFX88L/VFX44L V1...

  • Page 165: System Parameters

    • Call Hold Reject Timer: Refer chapter ‘Call Hold’ • Transfer Notification Timer: Refer chapter ‘Blind Call Transfer’ • Remote Held Reject Timer: Refer chapter ‘Call Hold’ Relevant Topics: 1. Blind Call Transfer 48 2. Call Hold 60 3. Ring Type 130 =X=X= SETU VFX88L/VFX44L V1...

  • Page 166: Voip Basics

    • User agent client (UAC)-A client application that initiates the SIP request. • User agent server (UAS)-A server application that contacts the user when a SIP request is received and that returns a response subject to user’s input. SETU VFX88L/VFX44L V1...
  • Page 167 Typically, a company maps its local inside network addresses to one or more global outside IP addresses and unmaps the global IP addresses on incoming packets back into local IP addresses. This helps ensure security since each outgoing or SETU VFX88L/VFX44L V1...
  • Page 168 SIP outbound server to handle voice calls. This allows the gateway to work with any type of NAT router and eliminates the need of STUN. Important Voice Parameters: Jitter Buffer: • The clarity of voice heard from the called party is also distorted due SETU VFX88L/VFX44L V1...
  • Page 169 (This allows the gateway to tag voice frames so they can be prioritized over the network) 1. Type of Service (ToS) 2. DiffServe ToS: • Network traffic can be classified by setting the ToS values at the SETU VFX88L/VFX44L V1...
  • Page 170 DiffServe-compliant network services along the route, based on the application types and traffic flow. Packets are marked with DiffServe Code Point (DSCP) indicating the level of service desired. Relevant Topic: 1. Glossary 182 =X=X= SETU VFX88L/VFX44L V1...

  • Page 171: Web Jeeves

    Matrix Web Jeeves Introduction Matrix supplies a special windows based software package to program the SETU VFX88L/VFX44L through the Internet, known as Jeeves. Description of following features related to web will help in programming the system: IP Address • An IP address (Internet Protocol address) is a unique number, similar in concept to a telephone number, used by network devices (computers, time-servers, FAX machines, some telephones).
  • Page 172 • While computers and network hardware work with IP addresses to perform tasks such as addressing and routing, humans generally find it easier to work with hostnames and domain names (such as www.example.com) in URLs and e-mail addresses. SETU VFX88L/VFX44L V1...
  • Page 173 • Password Change • Peer-to-Peer Dialing • Prefix to Domain Name Conversion • Ring Type • SIP Account Parameters-1 • SIP Account Parameters-2 • SIP Account Routing Groups • Soft Restart • Status • Supplementary Services • System Parameters SETU VFX88L/VFX44L V1...
  • Page 174 Web Pages: • After entering suitable IP Address in field of Internet Explorer 6 web page enter the following password as shown below: • The welcome page displays the time after which login expires as shown below: SETU VFX88L/VFX44L V1...
  • Page 175 • Click on web link ‘SIP Account Parameters-1’ and program ‘SIP User ID’ for SIP Account Number as shown below: SETU VFX88L/VFX44L V1...
  • Page 176 Matrix System Manual =X=X= SETU VFX88L/VFX44L V1...

  • Page 177: Section 3: Appendices

    Section 3: Appendices...

  • Page 179: Appendix A: Technical Specifications

    • Nine SIP Accounts can be programmed and 8-calls can be setup simultaneously (4 calls for VFX44L). • Call Progress Tone Generation: Select as per the country • QoS: RTP QoS and SIP QoS using DiffServ and ToS (Precedence) SETU VFX88L/VFX44L V1...
  • Page 180 • Programming Using Web Page • Phone Programming of some parameters like: • WAN IP Address • DND • Hotline LED Indication: 1 LED for Power 1 LED for each FXS Port 1 LED for System : Password Protected Administrator Security SETU VFX88L/VFX44L V1...
  • Page 181 Power Consumption : 20W (Typical) Environmental: Operating Temperature : -10°C to 50°C (140° to 122°F) Operating Humidity : 5-95% RH, Non-Condensing Storage Temperature : -40°C to 85°C (-40°F to 185°F) Storage Humidity : 0-95% RH, Non-Condensing =X=X= SETU VFX88L/VFX44L V1...

  • Page 182: Appendix B: Glossary

    It is Foreign Exchange Station. An FXS interface connects directly to a standard telephone and supplies ring, voltage, and dial tone. Matrix- Gateway’s FXS interface is an RJ-11 connector that allows connections to basic telephone service equipment and PBXs.
  • Page 183 • It is programmed into the card at the time of manufacture. IEEE registration authority administers MAC address scheme for all LANs which conform to IEEE, 802stds. Including both Ethernet and token ring. • Consists of two parts: 24-bit company id (manufacturer ID0 and 24-bit Extension ID (board ID). SETU VFX88L/VFX44L V1...
  • Page 184 User Datagram Protocol-A network protocol for transmitting data that does not require acknowledgment from the recipient of the data that is sent. It is the Voice activity detection, when enabled on a voice port or a dial SETU VFX88L/VFX44L V1...
  • Page 185 VoIP enables a gateway or router to carry voice traffic (for example, telephone calls and faxes) over an IP network. In VoIP, the DSP segments the voice signal into frames, which then are coupled in groups of two and stored in voice packets. =X=X= SETU VFX88L/VFX44L V1...

  • Page 186: Appendix C: Features At A Glance

    Set Do Not Disturb (DND) Cancel Do Not Disturb (DND) Set Call Waiting Cancel Call Waiting Retrieve Hold Call Hold Call Flash-1 Blind Transfer Flash-2 Release Call Waiting Call Flash-3 Accept Call Waiting Call Flash-4 Reject Remote Held Call Flash-5 =X=X= SETU VFX88L/VFX44L V1...

  • Page 187: Appendix D: Programming Commands

    11-XXXX XXXX XXXX XXXX-#* Address To program Subnet Mask 12-XXXX XXXX XXXX XXXX-#* To display the Network IP 21-#* Address on the Phone To display Subnet Address 22-#* To display Gateway Address 23-#* To display DNS Address 24-#* =X=X= SETU VFX88L/VFX44L V1...

  • Page 188: Index

    Dialed State Access Code-See Access Codes 29 DNS-See Network Port Parameters 113 Display of IP Address-See Programming Using Conventional Phone Fax Option-See SIP Account Parameters 149 First Free-See Member Selection Method 111 Flash Timer-See FXS Port Parameters 103 FSK-See CLIP 83 SETU VFX88L/VFX44L V1...
  • Page 189 Open Loop Disconnect-See Disconnect Signaling on FXS Port 93 Outbound Proxy-See SIP Account Parameters 149 Phone Book-See Routing Option-Dialed Number Based 139 Polarity Reversal-See Disconnect Signaling on FXS Port 93 PPPoE-See Network Port Parameters 113 Precedence-See Network Port Parameters 113 Public IP-See Status 159 SETU VFX88L/VFX44L V1...
  • Page 190 Substitute Number List-See Automatic Number Translation 36 System Parameters-See Call Hold 60 T.38-See Fax Over IP 101 Transferee-See Blind Call Transfer 48 Transferor-See Blind Call Transfer 48 Transfer Target-See Blind Call Transfer 48 Vocoder-See SIP Account Parameters 149 SETU VFX88L/VFX44L V1...
  • Page 191 System Manual Matrix WAN-See Network Port Parameters 113 Web Page-See Web Jeeves 171 =X=X= SETU VFX88L/VFX44L V1...

  • Page 192: Notes

    Matrix System Manual Notes SETU VFX88L/VFX44L V1...
  • Page 193 System Manual Matrix Notes SETU VFX88L/VFX44L V1...

  • Page 194: Programming Register

    Matrix System Manual Programming Register S.N. Date Major Programming Changes made SETU VFX88L/VFX44L V1...
  • Page 195 System Manual Matrix Programming Register S.N. Date Major Programming Changes made SETU VFX88L/VFX44L V1...

This manual is also suitable for:

Setu vfx44l

Table of Contents
