Feature
C states
C-State Auto Demotion
C-State Un-demotion
Package C-State Demotion
Package C-State Un-demotion
Package C State Limit
Tcc Activation Offset
9.3.2
Advanced > Graphics Configuration
Feature
Graphics Configuration
LVDS
eDP/LVDS
LFP Panel Type
BIOS Setup
Options
Disabled
Enabled
Disabled
C1
C3
C1 and C3
Disabled
C1
C3
C1 and C3
Disabled
Enabled
Disabled
Enabled
C0/C1
C2
C3
C6
C7
C7S
C8
C9
C10
Cpu Default
Auto
0-63
Default: 1
Options
Info only
Info only
Disabled
Enabled
VBIOS Default
640x480
800x600
1024x768
1280x1024
1400x1050
1266x768
1600x1200
1366x768
1680x1050
Description
Enable/Disable CPU Power Management. Allows
CPU to go to C states when it's not 100% utilized.
Configure C-State Auto Demotion
Configure C-State Un-demotion
Package C-State Demotion
Package C-State Un-demotion
Maximum Package C State Limit Setting. Cpu
Default: Leaves to Factory default value.Auto:
Initializes to deepest available Package C State Limit.
Offset from factory set Tcc activation temprature at
which the Thermal Control Circuit must be activated.
Tcc will be activated at: Tcc Activation Temp - Tcc
Activation Offset. Tcc Activation Offset range is 0 to
63.
Description
Enable/Disable eDP/LVDS
Select LFP panel used by Internal Graphics Device by
selecting the appropriate setup item.
AMSTX-CF Series
43
