Feature
HD Audio Configuration ►
PCH digital I/O device
SPD Write Disable
9.4.6 Chipset > PCH-IO Configuration > PCI Express Configuration
Feature
PCI Express Configuration
PCI Express Clock Gating
Pcie Pll SSC
9.4.7 Chipset > PCH-IO Configuration > SATA Configuration
Feature
SATA Configuration
SATA Mode Selection
Serial ATA Port 0
Serial ATA Port 2
58
Options Description
Sub-Menu HD Audio Subsystem Configuration Settings
Disable/Enable PCH digital I/O device
Disabled
Enabled
Enable/Disable setting SPD Write Disable. For
TRUE
security recommendations, SPD write disable bit
FALSE
must be set.
Options Description
Info only
Disabled Enabled PCI Express Clock Gating Enable/Disable
for each root port.
Enabled
Pcie Pll SSC percentage.AUTO - Keep hw default,
Auto
no BIOS override. Range is 0.0%-2.0%.
0.0%
0.1%
0.2%
0.3%
0.4%
0.5%
0.6%
0.7%
0.8%
0.9%
1.0%
1.1%
1.2%
1.3%
1.4%
1.5%
1.6%
1.7%
1.8%
1.9%
2.0%
Options Description
Info only
Determines how SATA controller(s) operate.
AHCI
Intel RST Premium
With Intel Optane
System Acceleration
Info only SATA device info
Info only SATA device info
