Specifications

2.1

Core System

CPU: Desktop 8th/9th Generation Intel® Core™ i7/i5/i3 Processor, LGA1151 socket
•
Intel® Core™ i7-9700E, 2.6GHz, 12M Cache, 65W TDP, LGA1151, DDR4 2666MHz support (8C/8T)
•
Intel® Core™ i7-9700TE, 1.8GHz, 12M Cache, 35W TDP, LGA1151, DDR4 2666MHz support (8C/8T)
•
Intel® Core™ i5-9500E, 3.0GHz, 9M Cache, 65W TDP, LGA1151, DDR4 2666MHz support (6C/6T)
•
Intel® Core™ i5-9500TE, 2.2GHz, 9M Cache, 35W TDP, LGA1151, DDR4 2666MHz support (6C/6T)
•
Intel® Core™ i3-9100E, 3.1GHz, 6M Cache, 65W TDP, LGA1151, DDR4 2400MHz support (4C/4T)
•
Intel® Core™ i3-9100TE, 2.2GHz, 6M Cache, 35W TDP, LGA1151, DDR4 2400MHz support (4C/4T)
•
Intel® Core™ i7-8700, 3.2GHz, 12M Cache, 65W TDP, LGA1151, DDR4 2666MHz support (6C/12T)
•
Intel® Core™ i7-8700T, 2.4GHz 12M Cache, 35W TDP, LGA1151, DDR4 2666MHz support (6C/12T)
•
Intel® Core™ i5-8500, 3.0GHz, 9M Cache, 65W TDP, LGA1151, DDR4 2666MHz support (6C/6T)
•
Intel® Core™ i5-8500T, 2.1GHz, 9M Cache, 35W TDP, LGA1151, DDR4 2666MHz support (6C/6T)
•
Intel® Core™ i3-8100, 3.6GHz, 6M Cache, 65W TDP, LGA1151, DDR4 2400MHz support (4C/4T)
•
Intel® Celeron® G4900, 3.1GHz, 2M Cache, 54W TDP, LGA1151, DDR4 2400MHz support (2C/2T)
•
Intel® Celeron® G4900T, 2.9GHz, 2M Cache, 35W TDP, LGA1151, DDR4 2400MHz support (2C/2T)
Chipset: Intel® Q370 or H310 Chipset
TPM: TPM 2.0 (optional)
Memory: Non-ECC DDR4 2666/2400 MHz, 2x SODIMM, up to 64 GB (dependent on CPU)
BIOS: AMI® UEFI BIOS, 256 Mb (Q370) or 128 Mb (H310) SPI flash memory
MXM Graphics Module Support:
•
AMSTX-CFP12-Q370/H310: EGX-MXM-P1000, EGX-MXM-P2000, EGX-MXM-T1000, EGX-MXM-
RTX3000, EGX-MXM-RTX5000
•
AMSTX-CFP35-Q370/H310: EGX-MXM-P3000, EGX-MXM-P5000
2.2

I/O Interface

PCB Edge Connector:
•
Q370 SKU: 1x PCIe x8 PCB edge connector (data is from 2x PCIe Gen3 x4 root ports, one set of clocks,
up to 50W), one PCIe power connector up to 12V@3.5A / 5V@4A
•
H310 SKU: 1x PCIe x8 PCB edge connector (data is from 1x PCIe Gen2 x1 root ports, one set of clocks,
up to 50W), one PCIe power connector up to 12V@3.5A / 5V@4A
LAN: 1x GbE (Intel® i219-LM), 3x GbE (Intel® i210-AT)
SATA:
•
Q370 SKU: 2x SATA 6Gb/s, one SATA power connector 2x SATA 6Gb/s signals via M.2 M & B key
connector, Intel® RST RAID Support
•
H310 SKU: 2x SATA 6Gb/s, one SATA power connector 1x SATA 6Gb/s signal via M.2 B key connector
USB:
•
Q370 SKU: 4x USB 3.2 Gen1 x1 ports, 2x USB 2.0 pin headers, 2x USB 3.2 Gen1 x1 pin headers
•
H310 SKU: 4x USB 3.2 Gen1 x1 ports, 4x USB 2.0 pin headers
DIO: 1x 10-pin/2.0mm wafer: DI/DO: 4 in and 4 out
COM: 1x RS-232/422/485 pin header, 1x RS-232 pin header (CCtalk supported by jumper setting)
