ADLINK Technology AMSTX-CF Series User Manual page 25

Pin
A13
A14
A15
A16
A17
A18
A19
A20
A21
A22
A23
A24
A25
A26
A27
A28
A29
A30
A31
A32
A33
A34
A35
A36
A37
A38
A39
A40
A41
A42
A43
A44
A45
A46
A47
A48
A49
Connector Pinouts
Signal
CLKOUT_PCIE_P7
CLKOUT_PCIE_N7
GND
GF_PCIEX21_RX_P
GF_PCIEX21_RX_N
GND
NC
GND
GF_PCIEX22_RX_P
GF_PCIEX22_RX_N
GND
GND
GF_PCIEX23_RX_P
GF_PCIEX23_RX_N
GND
GND
GF_PCIEX24_RX_P
GF_PCIEX24_RX_N
GND
NC
NC
GND
GF_PCIEX1_RX_P
GF_PCIEX1_RX_N
GND
GND
GF_PCIEX2_RX_P
GF_PCIEX2_RX_N
GND
GND
GF_PCIEX3_RX_P
GF_PCIEX3_RX_N
GND
GND
GF_PCIEX4_RX_P
GF_PCIEX4_RX_N
GND
Pin Signal
B13 GND
B14 GF_PCIEX5_21_TX_P
B15 GF_PCIEX5_21_TX_N
B16 GND
B17 PCH_CLK_REQ7-L
B18 GND
B19 GF_PCIEX22_TX_P
B20 GF_PCIEX22_TX_N
B21 GND
B22 GND
B23 GF_PCIEX23_TX_P
B24 GF_PCIEX23_TX_N
B25 GND
B26 GND
B27 GF_PCIEX24_TX_P
B28 GF_PCIEX24_TX_N
B29 GND
B30 NC
B31 PCH_CLK_REQ7-L
B32 GND
B33 GF_PCIEX1_TX_P
B34 GF_PCIEX1_TX_N
B35 GND
B36 GND
B37 GF_PCIEX2_TX_P
B38 GF_PCIEX2_TX_N
B39 GND
B40 GND
B41 GF_PCIEX3_TX_P
B42 GF_PCIEX3_TX_N
B43 GND
B44 GND
B45 GF_PCIEX4_TX_P
B46 GF_PCIEX4_TX_N
B47 GND
B48 PCH_CLK_REQ7-L
B49 GND
