4.2.11 DIO Connector (CN11)
Pin Signal
1 5V_12V_S
2 GND
3 DI0
4 DI1
5 DI2
6 DI3
7 DO0
8 DO1
9 DO2
10 DO3
4.2.12 12V DC-in Connector (CN3)
Pin Signal
1 GND
2 DCIN
3 GND
4 DCIN
5 GND
6 DCIN
7 GND
8 DCIN
4.2.13 PCB Edge Connector
Pin
A1 (pin 1 on bottom)
A2
A3
A4
A5
A6
A7
A8
A9
A10
A11
A12
16
Signal
GND B1 (pin 1 at top)
P_+12V_S
P_+12V_S
GND
JTAGE_CLK(NC)
JTAGE_DI(NC)
JTAGE_DO(NC)
JTAGE_MS(NC)
P_+3V3_S
P_+3V3_S
PCH_PLTRST-L_BUF
GND
Pin Signal
P_+12V_S
B2 P_+12V_S
B3 P_+12V_S
B4 GND
B5 PCH_SMB_CLK_A
B6 PCH_SMB_DAT_A
B7 GND
B8 P_+3V3_S
B9 JTAGE_RST(NC)
B10 P_+3V3_A
B11 X_PCIE_WAKE-L
B12 NC
