9.4 Chipset

9.4.1 Chipset > System Agent (SA) Configuration
Feature
System Agent (SA) Configuration
SA PCIe Code Version
VT-d
Memory Configuration ►
Graphics Configuration ►
PEG Port Configuration ►
VT-d
Above 4GB MMIO BIOS assignment
9.4.2 Chipset > System Agent (SA) Configuration > Memory Configuration
Feature
Memory Configuration
Memory RC Version
Memory Frequency
Memory Timings (tCL-tRCD-tRP-
tRAS)
DIMM 1
Size
Number of Ranks
Manufacturer
DIMM 2
Size
Number of Ranks
Manufacturer
Memory Remap
Fast Boot
56
Options Description
Info only
Info only SA PCIe Code Version
Info only Supported or not
Sub-Menu Memory Configuration Parameters
Sub-Menu Graphics Configuration
Sub-Menu PEG Port Options
Disable VT-d capability
Enable
Enable/Disable above 4GB MemoryMappedIO BIOS
Disable
assignment
Enable
Options Description
Info only
Info only Memory RC Version
Info only Memory Frequency
Info only Memory Timings (tCL-tRCD-tRP-tRAS)
Info only DIMM 1 info
Info only Size of DIMM 1
Info only Number of Ranks of DIMM 1
Info only Manufacturer of DIMM 1
Info only DIMM 2 info
Info only Size of DIMM 2
Info only Number of Ranks of DIMM 2
Info only Manufacturer of DIMM 2
Disable Enable/Disable Memory Remap above 4GB
Enable
Disable Enable/Disable fast path thru the MRC
Enable
