ADLINK Technology AMSTX-CF Series User Manual page 60

Feature
Data Bits
Parity
Stop Bits
Flow Control
VT-UTF8 Combo Key Support
Recorder Mode
Resolution 100x31
Putty KeyPad
9.3.16 Advanced > Trusted Computing [TPM 2.0 Configuration]
Feature
Configuration
Security Device Support
TPM 2.0 Configuration
TPM20 Device Found
Firmware Version:
Vendor:
Security Device Support
Active PCR banks
52
Options Description
7 Data Bits.
8
A parity bit can be sent with the data bits to detect
None
some transmission errors. Even: parity bit is 0 if the
Even
num of 1's in the data bits is even. Odd: parity bit is
Odd
0 if num of 1's in the data bits is odd. Mark: parity bit
Mark
is always 1. Space: Parity bit is always 0. Mark and
Space
Space Parity do not allow for error detection. They
can be used as an additional data bit.
Stop bits indicate the end of a serial data packet. (A
1
start bit indicates the beginning). The standard
2
setting is 1 stop bit. Communication with slow
devices may require more than 1 stop bit.
Flow control can prevent data loss from buffer
None
overflow. When sending data, if the receiving buffers
Hardware RTS/CTS
are full, a 'stop' signal can be sent to stop the data
flow. Once the buffers are empty, a 'start' signal can
be sent to re-start the flow. Hardware flow control
uses two wires to send start/stop
Disabled Enable VT-UTF8 Combination Key Support for
ANSI/VT100 terminals
Enable
With this mode enabled only text will be sent. This is
Disabled
to capture Terminal data.
Enable
Enables or disables extended terminal resolution
Disabled
Enable
Select FunctionKey and KeyPad on Putty.
VT100
LINUX
XTERMR6
SCO
ESCN
VT400
Options Description
Info only
Disable Enables or Disables BIOS support for security
device. O.S. will not show Security Device. TCG EFI
Enable
protocol and INT1A interface will not be available.
Info only
Info only
Info only
Info only
Disable Enables or Disables BIOS support for security
device. O.S. will not show Security Device. TCG EFI
Enable
protocol and INT1A interface will not be available.
Info only
BIOS Setup
