4.3.7 RS-232/CCtalk Selection (CN6)
RS-232/CCtalk
1-3
2-4
RS-232 (default)
7-9
8-10
3-5
4-6
CCtalk
9-11
10-12
4.3.8 Data Format and Color Depth Selection (SW1)
Data Format and Color Depth
1-4_ON
2-3_ON VESA 24bpp
1-4,2-3 OFF JEIDA 24bpp (default)
4.3.9 LVDS Channel Selection (SW2)
LVDS Channel
1-4_ON VESA (default)
1-4_OFF JEIDA
2-3_ON Signal (default)
2-3_OFF Dual
4.3.10 HSIO Selection (SW5)
HSIO selection
1-8_ON CN24 lower connector support USB3.0 (Default)
1-8_OFF M.2 B key support USB 3.0
2-7_ON M.2 B key support SATA (Default)
2-7_OFF M.2 B key support PCIe (BOM optional)
3-6 ON M.2 B key support USB 3.0 (Default)
3-6 OFF M.2 B key support PCIe (BOM optional)
22
18bpp
Connector Pinouts
