Mechanical Layout

3.1

Connector Locations

A B
Mechanical Layout
C D
E F

Figure 2: IO Panel Connector Locations

Table 1: IO Panel Connector Definitions

Item Description
A DisplayPort (from CPU)
B LAN (I210-AT)
C LAN (I210-AT)
D LAN (I219-LM)
E 2x USB 3.2 Gen1 x1
F 2x USB 3.2 Gen1 x1
G HDMI (from CPU)
H DisplayPort (from MXM)
I DisplayPort (from MXM)
J 12V DC-in connector
H
G
Remarks
CN1
RJ453
CN24
CN23
CN24
CN23
HDMI1
U13
U27
CN3
AMSTX-CF Series
I
J
