9.4.3 Chipset > System Agent (SA) Configuration > Graphics Configuration
Feature
Graphics Configuration
Graphics Turbo IMON Current
Primary Display
Internal Graphics
GTT Size
DVMT Total Gfx Mem
9.4.4 Chipset > System Agent (SA) Configuration > PEG Port Configuration
Feature
PEG Port Configuration
PEG[Bus, Dev, Fun]
Enable Root Port
Max Link Speed
PCIe Spread Spectrum Clocking
9.4.5 Chipset > PCH-IO Configuration
Feature
PCH-IO Configuration
PCI Express Configuration ►
SATA Configuration ►
USB Configuration ►
Security Configuration ►
BIOS Setup
Options Description
Info only
14-31 Graphics turbo IMON current values supported (14-
31)
Default: 31
Auto Select which of IGFX/PEG Graphics device should
be Primary Display.
IGFX
PEG
Auto Keep IGFX enabled based on the setup options.
Disabled
Enabled
2MB Select the GTT Size
4MB
8MB
128M Select DVMT5.0 Total Graphic Memory size used by
the Internal Graphics Device.
256M
MAX
Options Description
Info only
Info only PEG location and info
Disabled Enable or Disable the Root Port
Enabled
Auto
Configure PEG[Bus, Dev, Fun] Max Speed
Auto
Gen1
Gen2
Gen3
Disable Allows disableing Spread Spectrum Clocking for
compliance testing
Enable
Options Description
Info only
Sub-Menu PCI Express Configuration settings
Sub-Menu SATA Device Options Settings
Sub-Menu USB Configuration settings
Sub-Menu Security Configuration settings
