Figure 3: Onboard Connector Locations- Top Side; Table 2: Onboard Connector Definitions - Top Side - ADLINK Technology AMSTX-CF Series User Manual

E E
D D
d d
Item Description
A CPU socket
B DRAM socket for DIMM1
C DRAM socket for DIMM2
D CPU Fan connector
E System fan connector
F 2x USB2.0 pin header (CN22)
G RS-232 pin header for COM1 (CN7)
H RS-232/422/485 pin header for COM2 (CN8)
I 2x USB 3.2 Gen1 x1 pin headers (Q370)
2x USB 2.0 pin headers (H310)
J Multi-purpose connector (CN6)
K Audio pin header (CN9)
L PCIe power connector (CN10)
M SATA connector (SATA1)
N SATA connector (SATA2)
O SATA power connector (CN14)
P Power on module connector (CN12)
Q DIO connector (CN11)
8
G G H H
F F
A A
c c b b a a

Figure 3: Onboard Connector Locations- Top Side

Table 2: Onboard Connector Definitions - Top Side

Item Description
I I J J
C C
B B
e e f f
S S
Z Z Y Y X X
R Panel backlight power and resolution jumper (CN13)
S MXM connector (CN5)
T PCB edge connector
U RTC battery connector (CN16)
V GPU fan connector
W 12V DC in connector (CN3)
X Display port C and Display port D from MXM
Y Display port A and Display port B from MXM
Z HDMI from CPU
a LAN1 and USB 3.2 Gen1 x1 ports 1/2
b LAN4 and USB 3.2 Gen1 x1 ports 3/4
c LAN2 and LAN3
d Display port 1 and Display port 2 from CPU
e BMC status LED (LED2, Blue)
f BMC watchdog LED (LED3, Red)
g Data format and Color Depth selection for LVDS (SW1)
K K
M M
L L
N N
O O
P P
g g
Q Q
R R
T T
U U
V V
W W
