9.3.18 Advanced > NVMe Configuration
Feature
NVMe Configuration
List NVMe Device
9.3.19 Advanced > Network Stack Configuration
Feature
Network Stack
Ipv4 PXE Support
Ipv4 HTTP Support
Ipv6 PXE Support
Ipv6 HTTP Support
IPSEC Certificate
PXE boot wait time
Media detect count
9.3.20 Advanced > [Network Name] Network Configuration
Feature
This sub-menu provided by device firmware, please refer to the actual layout.
9.3.21 Advanced > RAM Disk Configuration
Feature
Disk Memory Type:
Create raw ►
Create from file ►
Created RAM disk list:
Remove selected RAM disk(s)
54
Options Description
Info only
Info only
Options Description
Enable/Disable UEFI Network Stack
Disable
Enable
Enable/Disable IPv4 PXE boot support. If disabled,
Disable
IPv4 PXE boot support will not be available.
Enable
Enable/Disable IPv4 HTTP boot support. If disabled,
Disable
IPv4 HTTP boot support will not be available.
Enable
Enable/Disable IPv6 PXE boot support. If disabled,
Disable
IPv6 PXE boot support will not be available.
Enable
Enable/Disable IPv6 HTTP boot support. If disabled,
Disable
IPv6 HTTP boot support will not be available.
Enable
Disable Support to Enable/Disable IPSEC certificate for Ikev.
Enable
Wait time in seconds to press ESC key to abort the
0-5
PXE boot. Use either +/- or numeric keys to set the
Default: 0
value.
1-50 Number of times the presence of media will be
checked. Use either +/- or numeric keys to set the
Default: 1
value.
Options Description
Options Description
Specifies type of memory to use from available
Boot Service Data
memory pool in system to create a disk.
Reserved
Sub-Menu Create a raw RAM disk.
Sub-Menu Create a RAM disk from a given file.
Info only
Remove selected RAM disk(s)
