Feature
Available PCR banks
SHA-1 PCR Bank
SHA256 PCR Bank
Pending operation
Platform Hierarchy
Storage Hierarchy
Endorsement Hierarchy
TPM2.0 UEFI Spec Version
Physical Presence Spec Version
PH Randomization
9.3.17 Advanced > S5 RTC Wake Settings
Feature
RTC Wake system from S5
Wake up hour
Wake up minute
Wake up second
Wake up minute increase
BIOS Setup
Options
Description
Info only
Disabled
Enable or Disable SHA-1 PCR Bank
Enabled
Disabled
Enable or Disable SHA256 PCR Bank
Enabled
Schedule an Operation for the Security Device.
None
NOTE: Your Computer will reboot during restart in
TPM Clear
order to change State of Security Device.
Disabled
Enable or Disable Platform Hierarchy
Enabled
Disabled
Enable or Disable Storage Hierarchy
Enabled
Disabled
Enable or Disable Endorsement Hierarchy
Enabled
TCG_1_2
Select the TCG2 Spec Version Support
TCG_2
1.2
Select to Tell O.S. to support PPI Spec Version 1.2
or 1.3. Note some HCK tests might not support 1.3.
1.3
Disabled
Enables or Disables Platform Hierarchy
randomization. DO NOT ENABLE THIS QUESTION
Enabled
IN PRODUCTION PLATFORMS. THIS IS FOR
DEVELOPMENT TESTING. OVERRIDE
ChangePlatformAuth ELINK for production platforms
supporting TXT.
Options
Description
Enable or disable System wake on alarm event.
Disabled
Select FixedTime, system will wake on the
Fixed Time
hr::min::sec specified. Select DynamicTime , System
Dynamic Time
will wake on the current time + Increase minute(s)
0-23
Range: 0-23 hr
For example enter 3 for 3am and 15 for 3pm
Default: 0
0-59
Range: 0-59 min
Default: 0
0-59
Range: 0-59 sec
Default: 0
1-5
Range: 1-5 min
Default: 1
AMSTX-CF Series
53
