Feature
COM1 Control
Ring1 Wake
COM2 Device Settings
COM2 Control
Ring2 Wake
9.3.14 Advanced > Serial Console Redirection
Feature
Serial Console Redirection
COM1
Console Redirection
Console Redirection Settings ►
COM2
Console Redirection
Console Redirection Settings ►
9.3.15 Advanced > Console Redirection Settings [COM1-2]
Feature
COM[1-2]
Console Redirection Settings
Terminal Type
Bits per second
BIOS Setup
Options Description
Select COM1 mode. RS232 only
RS232
Disabled Disable/Enable RI ping for Wake On Ring function(PCH
PME# signal)
Enabled
Info only IO=2F8; IRQ=3;
Select COM2 mode. RS232, RS422 or RS485
RS232
RS422
RS485
Disabled Disable/Enable RI ping for Wake On Ring function(PCH
PME# signal)
Enabled
Options
Info only
Info only
Disabled
Enabled
Submenu
Info only
Disabled
Enabled
Submenu
Options
Info only
VT100
VT100+
VT-UTF8
ANSI
9600
19200
38400
57600
115200
Description
Console Redirection enable or disable.
The settings specify how the host computer and the
remote computer (which the user is using) will
exchange data. Both computers should have the
same or compatible settings.
Console Redirection enable or disable.
As above.
Description
Emulation: ANSI: Extended ASCII char set. VT100:
ASCII char set. VT100+: Extends VT100 to support
color, function keys, etc. VT-UTF8: Uses UTF8
encoding to map Unicode chars onto 1 or more
bytes.
Selects serial port transmission speed. The speed
must be matched on the other side. Long or noisy
lines may require lower speeds.
