Introduction

Embedded graphics enable system developers to boost the performance of a wide range of workloads, including
medical imaging, image analysis, compute acceleration, and artificial intelligence (AI). Leveraging graphics
processing units (GPUs), embedded graphics can be used to increase application speed and accuracy, as well as
decrease latency. Many embedded system developers use embedded graphics solutions in real-world applications
from the medical and manufacturing industries, to traffic management. System developers, OEMs, and system
integrators can more easily deploy embedded graphics with support from ADLINK's large portfolio of computing
products designed in a wide range of form factors. The AMSTX-CF Series Micro-STX motherboard features a
socket-type CPU and support for Scalable Graphics Processing Ranging from Pascal to Turing GPUs in a compact
form factor. Combining its strong expertise serving embedded developers and its close relationship with NVIDIA,
ADLINK is delivering high-performance, long-life embedded graphics solutions for a variety of market segments.
1.1

Packing List

•
AMSTX-CF embedded motherboard
•
CPU cooler bracket (P/N: 32-50015-0100-A0)
•
M3 screw, P-head, L4, Ni for M.2 E/B/M Key (P/N: 33-03013-0040) (3 for Q370, 2 for H310)
•
2x M3 screw, I-head, L4, Nylok for MXM (P/N: 33-03306-0040)
1.2

Available Models

AMSTX-CFP12-Q370
Model
EGX-MXM-P1000
EGX-MXM-P2000/
MXM
EGX-MXM-T1000
Support
EGX-MXM-RTX3000
EGX-MXM-RTX5000
Chipset
1.3

Optional Accessories

•
65W CPU cooler (P/N: 32-20495-0000)
•
35W CPU cooler (P/N: 32-20378-0000-A0)
•
MXM cooler for P1000/P2000 (P/N: 32-20797-0200-A0)
•
MXM cooler for P3000/P5000 (P/N: 32-20823-0020-A0)
•
MXM cooler for T1000 (P/N: 32-20830-0200-A0)
•
MXM cooler for RTX3000 (P/N: 32-20823-1100-A0)
•
MXM cooler for RTX5000 (P/N: 32-20839-1000-A0)
•
12V/240W adaptor (P/N: 31-62164-0010-A0)
•
500W power supply (12V/41.7A) (P/N: 91-95296-000E)
•
Wi-Fi Kit Intel® Wireless-AC 9260 non-vPRO (P/N: 91-95266-0020)
•
AMSTX/DLAP-3000 CPU cooler bracket (included by default) (PN: 32-50015-0100-A0)
Introduction
AMSTX-CFP35-Q370
EGX-MXM-P3000
EGX-MXM-P5000
Intel® Q370 Chipset
AMSTX-CFP12-H310
EGX-MXM-P1000
EGX-MXM-P2000
EGX-MXM-1000
EGX-MXM-RTX3000
EGX-MXM-RTX5000
Intel® H310 Chipset
AMSTX-CF Series
AMSTX-CFP35-H310
EGX-MXM-P3000
EGX-MXM-P5000
