Feature
Spreading depth
Data format and Color Depth
LVDS Output Mode
DE Polarity
Vsync Polarity
Hsync Polarity
LVDS Backlight Mode
LVDS Backlight Brightness
9.3.3 Advanced > Power Consumption
Feature
Power Consumption
Enable ACPI Auto Configuration
Enable Hibernation
ACPI Sleep State
Lock Legacy Resources
44
Options
1920x1200
1440x900
1600x900
1024x768
1280x800
1920x1080
2048x1536
No Spreading
0.5%
1.0%
1.5%
2.0%
2.5%
VESA 24 bpp
JEIDA 24 bpp
JEIDA/vesa 18 bpp
Dual LVDS bus
Single LVDS bus
Active High
Active Low
Active High
Active Low
Active High
Active Low
BMC Mode
GTT Mode
BMC Mode: 0-255
Default: 255
GTT Mode: 0-100
Default: 100
Options
Info only
Disabled
Enabled
Disabled
Enabled
Suspend Disabled
S3 (Suspend to RAM)
Disabled
Enabled
Description
Clock frequency center spreading depth.
Data format and Color Depth select
Single/Dual mode select
DE Polarity select
Vsync Polarity select
Hsync Polarity select
Select LVDS Backlight control function.
Set LVDS Backlight Brightness Percentage.
A change takes effect immediately.
Description
Enables or Disables BIOS ACPI Auto Configuration.
Enables or Disables System ability to Hibernate
(OS/S4 Sleep State). This option may not be effective
with some operating systems.
Select the highest ACPI sleep state the system will
enter when the SUSPEND button is pressed.
Enables or Disables Lock of Legacy Resources
