1.5

Specifications

1.5.1

Physical

Table 1-2 lists the physical dimensions of the carrier.
Item
Weight 0.42 kg
Height (overall) 33 mm
Board thickness 2 mm
Width 170 mm
Length 237 mm
1.5.2

Electrical

Table 1-3 specifies the voltage inputs of the carrier.
Parameter
Standard
RTC
BattMan Supply
1.5.3

Environmental

Most components on the LEC-BASE MINI carrier are selected as extended temperature range
parts (-40°C to +85°C). Some components are not available in this temperature range. In these
cases, the component temperature ranges are narrower. The LEC-BASE MINI is validated in
the -40°C to +85°C range.
The overall system performance depends on the combination of module and carrier subsys-
tems. Some SMARC modules are available in the industrial temperature range. Others are com-
mercial temperature range parts. Similar considerations apply to any of the add-on cards or
peripherals that are used with the LEC-BASE MINI.
Table 1-4 defines the environmental conditions under which the carrier is qualified to operate
and to be stored.
Parameter
Temperature
 Operating
 Storage
Humidity
 Operating
 Non-operating
Product Overview
Table 1-2: Weight and Footprint Dimensions
Dimension
Table 1-3: Carrier Voltage Inputs
Value
12V +/-5% and 5V +/-5% from ATX connector
3.0V, 2.0V to 3.3V (battery), +/-20mV ripple
12V +/-5% (3A max), 5.0V +/-5% (4A max), +/-50mV ripple
Table 1-4: Validated Temperature and Humidity Ranges
Value
 -40°C to +85°C
 -55°C to +85°C
 5% to 90% relative humidity, non-condensing
 5% to 95% relative humidity, non-condensing
Overall height is measured from the upper board
surface to the top of the highest permanent
component on the upper board surface. This
measurement does not include the cooling solution,
which can vary. The cooling solution will probably
increase this dimension.
