Loading Container Maintenance
10.Raise and lower the bucket a few times to test the cushions and verify the overall
performance of the loading bucket mechanism.
A
LWAYS WEAR A SAFETY HARNESS WHEN PERFORMING ANY MAINTENANCE ON THE ROOF
A
DJUSTMENT SCREW
FIGURE 1-52. Loading bucket cushion adjustment screw and holding valve
11. Remove the safety pin and perform a few cycles to test the adjustment.
A
LWAYS TURN OFF THE ENGINE AND THE HYDRAULIC SYSTEM WHEN PERFORMING TASKS ON
.
THE ROOF
Top Select Maintenance Manual
DANGER
H
OLDING VALVE
DANGER
.
1-57
