Loading Container Maintenance
2. Raise the bucket half way to verify it's parallel to the body.
3. If you noticed any horizontal unbalance while raising the bucket, you need to adjust
the holding valve to meet this requirement.
Lift the loading bucket all the way up to gain access to the cylinder.
•
Install the safety pins. See
•
Target the end of the bucket that is lower in the unbalance.
•
On the cylinder locate the holding valve and turn it
•
H
OLDING VALVE
FIGURE 1-47. Bucket hydraulic cylinder
Lower the bucket and test by lifting it and using the body guides as reference.
•
N : T
OTE HE TOLERANCE FOR THE HORIZONTAL ALIGNMENT IS
Top Select Maintenance Manual
section 1.3.7 on page
C
USHION DOWN
14.
½
turn CCW.
C
USHION UP
½
.
INCH
1-53
