Top Select Maintenance Guide
FIGURE 1-61. Tailgate limit switch
1.7.5
Body Chassis Hinges Inspection
Monthly lubrication of the body-Chassis hinges should be done. Also, inspect for cracks
or corrosion. Any crack must be reported and repaired by qualified personnel. Contact
Labrie Plus for technical support if required.
Keep the contact surface clean between the body and chassis. Labrie recommends
cleaning after every unloading.
FIGURE 1-62. Clean area between chassis and body
1.7.6
Body Raised Limit Switch
A limit switch located on the truck chassis activates the backup alarm and a warning
buzzer sounds as soon as the body is about one foot above the chassis. Adjust the limit
½
switch to about 4
1-64
inches from the pillow block.
Top Select Maintenance Manual
